Factory Direct Sell Vertical Metal Slotting Machine BK5030 With CE Standard
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Heavy Duty BC50125 Metal Slotting Machine With CE From China Factory
-
Vertical Metal Slotting Machine BC50100 Factory Direct Sell
-
Factory Direct Sell Vertical Metal Slotting Machine BK5035 With CE Standard
-
Factory Direct Sell Vertical Metal Slotting Machine BK5032 With CE Standard
-
Vertical Metal Slotting Machine BC5063 With CE Standard Factory Direct Sell
-
Y3150ET Standard Precision Hobbing Machine With Competitive Price
Product Description
Product Description
Machine features of slotting machine:
1. Suitable for processing of keyway spline and the inner keyway of blind hole;
2. High motor power, strong rigidity，Large precision margin, cheap price and Long service life;
3. Popular for machine and cars manufacture and has been widely applied in many industries as those of spaceflight and aviation, machine and electric;
4. Best choice for various materials and keyway machining.Specification | BK5030 | BC5032 |
The maximum length of ram | 300mm | 320mm |
Ram adjustment stroke | 300mm | 315mm |
Number of ram movement | 20/80n/min | 20/32/50/80n/min |
Working desk size | 550×405mm | 600×320mm |
table travel(X,Y) | 280×330mm | 620×560mm |
The distance between the axis of the tool bearing hole and the forearm of the column | 505mm | 600mm |
The distance between the end face of the cutter head support hole and the table | 540mm | 590mm |
X direction motor torque | 6(N/M) | 7.7(N/M) |
Y direction motor torque | 6(N/M) | 7.7(N/M) |
Fast-moving | 5X(m/min) | 5X(m/min) |
5Y(m/min) | 5Y(m/min) | |
Ball screw(X) | FFZD3205-3/P4 | FFZD3205-3/P4 |
Ball screw(Y) | FFZD3205-3/P4 | FFZD3205-3/P4 |
Main motor power | 3.7KW | 4KW |
Machine tool weight(about) | 2800kg | 3700kg |
package dimensions | 2300/2200/2300mm | 2800/2400/2500mm |
