Home > Products > SHAPING & SLOTTING MACHINE > Factory Direct Sell Vertical Metal Slotting Machine BK5032 With CE Standard
Factory Direct Sell Vertical Metal Slotting Machine BK5032 With CE Standard
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Vertical Metal Slotting Machine BC5063 With CE Standard Factory Direct Sell
-
Y3150ET Standard Precision Hobbing Machine With Competitive Price
-
Y3180H Standard Precision Hobbing Machine With CE Standard
-
3180-CNC2 Numerical Control Hobbing Machine With Good Accuracy
-
3150E-CNC4 High Quality Hobbing Machine With CE Standard
-
3150-CNC2 High Quality Hobbing Machine for Gear Processing
Product Description
Product Description
Factory direct sell vertical metal slotting machine BK5032 with CE standard
Machine features of slotting machine:
1. Full protection.
2. Equipped with external hand wheel.
3. The main motor is the servo motor.
1. Full protection.
2. Equipped with external hand wheel.
3. The main motor is the servo motor.
4. Optional TK13250 CNC rotary table is available.
5. The Y-axis screw nut type is preloaded with double nuts.
6. The vertical degree of Z direction and Y axis is no more than 0.02mm.
7. The rotary table is controlled by knd1000m-c numerical control system.
8. The transmission mode is synchronous belt transmission with low noise and high transmission power.
8. The transmission mode is synchronous belt transmission with low noise and high transmission power.
Specification | unit | BK5032 | BK5040 |
The maximum length of ram | mm | 320 | 400 |
Ram adjustment stroke | mm | 315 | 315 |
Number of ram movements | n/min | 20-80 | 20-80 |
working desk size | mm | 800x610 | 800x610 |
Table travel (X, Y) | mm | 350x400 | 350x400 |
The distance between the axis of the tool bearing hole and the forearm of the column | mm | 600 | 600 |
The distance between the end face of the cutter head support hole and the table | mm | 540 | 620 |
X direction motor torque | (N.M) | 7.7 | 7.7 |
Y direction motor torque | (N.M) | 7.7 | 7.7 |
Fast-moving | X(m/min) | 5 | 5 |
Y (m/min) | 5 | 5 | |
Ball screw (X) | FFZD3205-3/P4 | FFZD3205-3/P4 | |
Ball screw (Y) | FFZD3205-3/P4 | FFZD3205-3/P4 | |
Main motor power | KW | 4 | 4 |
Machine tool weight (about) | KG | 3700 | 3700 |
Package dimensions | mm | 2800/2400/2500 | 2800/2400/2500 |
Details Images
Application
Company Profile
Professional Service
Customers' Feedback
FAQ
Q1: How
is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
