Automatic Shaping Machine Metal BC6063 From Chinese Factory
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
New Product Shaper Machine B635A Shaping Machine Metal
-
Metal Shaping Machine Tool BC6050 Shaper Machine New
-
Heavy Duty BC6085 Horizontal Metal Shaping Mechanical Planer Machine
-
Maintenance Horizontal of Shaping Planer BC6066 Shaper Machine
-
Metal Shaper Machine Horizontal Gear Planer BC6050 Shaping Machine
-
High Precision Heavy Duty BC60100 Metal Mechanical Horizontal Shaping Machine
Product Description
Product Description
Product main features:
1. Feed system of shaper with a cam mechanism, adjust the feed quantity. Change the amount of knife, very convenient.
2. Shaper workbench can about rotational angle worktable moving structure with lateral and lifting; to planing inclined
plane,thereby expanding the scope of use.
2. Shaper workbench can about rotational angle worktable moving structure with lateral and lifting; to planing inclined
plane,thereby expanding the scope of use.
3. The sliding pillow and bed rails and with speed gear pair and the main rail sliding surface, lubrication oil pump has played for circulating lubrication.
4. Shaper with parking brake mechanism, so the speed of transformation. When starting machine tools and parking, the power supply can not be cut off.
4. Shaper with parking brake mechanism, so the speed of transformation. When starting machine tools and parking, the power supply can not be cut off.
5. Shaper in knife system overload safety device is installed, when due to careless handling or by external influence and cutting overload when, take the knife itself slipping, nondestructive parts which guarantees the machine to normal operation.
Specification | BC6063 |
Maximum planing length | 630mm |
Maximum distance from the bottom of the working table | 385mm |
lateral travel | 630mm |
Vertical stroke | 360mm |
Tool frame travel | 120mm |
Sleeper reciprocating times (per minute) | 14/20/28/40/56/80 |
Main motor power | 3W |
The maximum size(width*thickness)of the handle | 20×30mm |
The size of the T groove in the center of the worktable | 18mm |
Angle of rotation | ±60°(toolpost) |
Workbench size | 630×400/660×400mm |
Shape size | 2000×1300×x150mm |
Machine tool weight (about) | 1750/1870KG |
Package dimensions | 2000/1300/1650mm |
Details Images
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
Company Profile
Jingjiang Fuji Technology Co., Ltd.
Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
