Price of Vertical Shaper Machine B5032 for Metal Vertical Slotting Machine

Name: Price of Vertical Shaper Machine B5032 for Metal Vertical Slotting Machine
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Specification

Specification	Model B5020	Model B5032
Ram stroke	220mm	340mm
Max length of the ram slotting	200mm	320mm
Ram movement times	32.50.80.125 time min	20.32.50.80 time min
Tiltram	0-8°	0-8°
Table dia.	500mm	630mm
Vertical adjustment of ram distance	230mm	315mm
Head bearing surface to the bed from the front walls	485mm	600mm
Between the work surface to the lower carriage distance	320mm	490mm
Table max.longitudinal movement distance	500mm	630mm
Table max. lateral movement distance	500mm	560mm
Max. swivel table	360°	360mm
Table aspect motorized feed range	0.08-1.21	0.08-1.21
Table rotation feed range	0.052-0.783	0.052-0.783
Main motor	3kw	4kw
Motor speed (calulated value)	1430 r/min.	960 r/min.
Machine weight	2200 kg	3000 kg
Overal dimension	1916×1305×1995mm	2261×1495×2245mm

Company Profile

Jingjiang Fuji Technology Co., Ltd.

Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.

Contact Us

Jingjiang Fuji Technology Co., Ltd.: Contact nameJack Xu; Phone86-188-52690200
