CKX6830 Cheap Cnc Lathe Machine CNC Turning Center
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Wmt Cnc Lathe CK6432 500mm Cnc Lathe Machine Automatic for Sale
-
QK1343 CNC Lathe CNC Pipe Threading Lathe Machine With CE/ISO
-
CK5116 Single Column CNC Vertical Lathe Machine for Heavy Cutting
-
DVT5235C Double Column Vertical Manual Lathe Machine With CE
-
High Speed CK35GD 350 Mmcnc Lathe Manufacturers With Linear Guide and Power Turret for Sale
-
Desktop Cnc Lathe CNC180 Benchtop Cnc Lathe Machine for Training and Hobby Use
Product Description
Features:
1.Integrated slant bed structure.easy liquid leaking, high rigidity and good operation.
2.High speed at 5000r/min. First-class precision spindle bearing.
3.High precision ball screw Rexroth, fast feeding for high working efficiency.
4.All-closed stainless steel protection, strong liquid protection without any water leak.
5.8-12 position hydraulic turret, easy machining for complex parts.
Specification | CKX6830(CK42T) |
Max.swing over bed | 420mm |
Max.swing over cross slide | 350mm |
Max.maching diameter(disk/rod) | 200mm/60mm |
Max.length of work piece | 340mm |
spindle bearing diameter | 80mm |
Spindle bore diameter | 52mm |
Spindle nose | A2-5 |
Spindle speed range | 60-5000r/min |
Power of the main motor | 5.5-7.5kw |
Min.input unit | 0.0005/0.001mm |
Rapid speed | 20/20m/min |
Hydraulic chuck | 6" |
Hydraulic station | 8 |
Max .tool shank | 20x20mm |
Max.dia for boring size | 25mm |
Quill diameter | 80mm |
Quill travel | 80mm |
Packing size | 2125x1345x1640mm |
N.W/G.W | 3000/3400kgs |
Standard Equipment:
CNC control system: Fanuc or Siemens or Mitsubishi as you select
Spindle bearing: Japan NSK or Germany FAG P4 class.
Hydraulic chuck: Japan HOWA Hollow
Hydraulic cylinder: Japan HOWA Hollow
Linear guideway: Japan THK or Germany Rexroth.
Leadscrew: Taiwan Yintai precision ball screw
Leadscrew bearing: Japan NSK or Germany ESKY
Turret: Taiwan Liuxing 8 positions
Hydraulic station: Made in Taiwan famous brand
Alarm lamp
Auto-lubricating system
Cooling system
Optional Accessories:
Hydraulic turret: 12-Position
Auto chip conveyor
Auto bar feeding
