Features:
1.Integrated slant bed structure.
2.High speed at 5000r/min. First-class precision spindle bearing.
3.High precision ball screw Rexroth, fast feeding for high working efficiency.
4.All-closed stainless steel protection, strong liquid protection without any water leak.
5.Gang feed tool structure, quickly changing tool, and high repeated positioning accuracy 0.003mm.
Specification | CK28/300 | CK32/300 | ||
Swing over bed | 280mm | 320mm | ||
Swing over carriage | 120mm | 140mm | ||
Max.machining dia.(disk) | 160mm | 200mm | ||
Max.Length of workpiece | 150/200mm | 200/250mm | ||
Bedway slant degree | 45° | 50° | ||
Spindle bore | 40mm | 52mm | ||
Spindle nose | A2-4 | A2-5 | ||
Spindle speed range | 60-5000r/min | 60-5000r/min | ||
Hydraulic chuck | 5 | 6 | ||
Bar auto-feeding bore | 30mm | 42mm | ||
X/Z-axis travel | 300/250mm | 300/250mm | ||
X/Z-axis rapid speed | 12/16m/min | 12/16m/min | ||
X/Z-axis repositioning accuracy | 0.003mm | 0.003mm | ||
Size of gang tools worktable | 630/220mm | 690/265mm | ||
Toolpost | gangtools or hydraulic turret, you can select | |||
Power of main motor | 3.0kw | 5.5-7.5kw | ||
Min.input unit | 0.0005/0.001mm | 0.0005/0.001mm | ||
Max.tool shank | 20x20mm | 20x20mm | ||
Max.dia for boring bar | 25mm | 25mm | ||
Packing size | 1500x1200x1500mm | 1480x1600x1210mm | ||
N.W/G.W | 1800/2100kgs | 2600/3000kgs | ||
Standard Equipment:
CNC control system: FANUC, GSK or SIMENS as you select
Spindle bearing: Japan NSK or P4 class spindle bearings, Germany
Guideway: Japan THK or Germany Rexroth precision linear guide
Leadscrew: Taiwan Yintai precision ball screw
Frequency inverter: JapanYaskawa
Spindle chuck: HGD Precision collet chuck
Oil cylinder: HGD hollow hydraulic cylinder
Turret: Precision gangtools
Hydraulic station: Made in Taiwan famous brand
Alarm lamp
Auto-lubricating system
Cooling system
Optional Accessories:
Hydraulic turret: 8-Position
5"Hollow hydraulic chuck
Auto chip conveyor
Auto bar feeding
