CNC210 Benchtop Cnc Lathe for School Education and DIY Hobby Users
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CK45 Slant Bed CNC Lathe MachineNegotiableMOQ: 1 -
CAK6161X750 High Precision and Cheap Price Horizontal CNC Lathe Machine SpecificationNegotiableMOQ: 1
-
SK50P 500mm Mini Lathe Cnc for Metal WorkNegotiableMOQ: 1
-
CK0640 High Precision Benchtop Cnc Lathe With Pneumatic ChuckNegotiableMOQ: 1
-
CK0640 High Precision Benchtop CNC Lathe for Metal WorkingNegotiableMOQ: 1
Product Description
CNC120 CNC Lathe with below features:
1.The machine can process precisely internal or external diameter,face,taper and threading with high efficiency.
2.DC brushless spindle motor
3.Small occuping,lower energy consumption,easy operation,suitable for small processing
4,High-quality spindle by high-precision grinding and support by Angular contact bearing
5.Induction harden bed-way,Bed saddle with plastic sticker can improve the accuracy and service life of machine
6.Macro arithmetic operation can be performed,the processing of complex parts,fully functional,economical and practical with a textbook for teaching.
Specification |
CNC210 |
Max swing over bed |
210mm |
Max.swing over carriage |
100mm |
Max.length of work pieces |
250mm |
Spindle bore |
26mm |
Spindle taper |
MT4 |
Spindle speed |
100-3000rpm |
Metric thread cutting |
0.25-4mm |
Inch thread cutting |
6-80TPI |
Electric toolpost |
4-position |
Gangtool bar size |
12mm |
X Travel |
90mm |
Z travel |
300mm |
X Moving speed |
2000mm/min |
Z Moving speed |
2000mm/min |
Spindle motor power |
1.2kw |
X Motor power |
2NM |
Z Motor power |
2NM |
Mini setting unit |
0.001mm |
Tailstock diameter |
22m |
Tailstock Travel |
50mm |
Tailstock taper |
MT2 |
Overall size |
1185X930X1440mm |
Net weight |
300kgs |
