Home > Products > VERTICAL MACHINING CENTER > Vertical Milling Center VMC640L Linear Guideway CNC Milling Machine Price With Good Precision
Vertical Milling Center VMC640L Linear Guideway CNC Milling Machine Price With Good Precision
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
VMC500L 500/400/450 mm Cnc Machining Center
-
VMC1300L 4 Axis CNC Mill Machinery Center for Sale
-
HMC630D High Precision Single/double Positions Horizontal Machining Center CNC Horizontal Machining Center
-
HMC1000 High Precision CNC Double Positions Horizontal Machining Center CNC Horizontal Machining Center
-
High Precision HMC500 CNC Double Positions Horizontal Machining Center CNC Horizontal Machining Center
-
HMC800 High Precision CNC Double Positions Horizontal Machining Center CNC Horizontal Machining Center
Product Description
Products Recommend
Product Description
Specification
Specification | VMC600L | VMC640L |
Worktable size(LxW) | 800x400mm | 900x400mm |
T-slot (NxWx D) | 3x14x100mm | 3x18x100mm |
X/Y/Z axis travel | 600/400/450mm | 640/400/500mm |
Distance from spindle center to column | 450mm | 476mm |
Distance from spindle nose to worktable surface | 100-550mm | 120-620mm |
Spindle taper | BT40 | BT40 |
Spindle power | 5.5kw | 5.5kw |
Max.spindle speed | 10000rpm | 8000rpm |
Max.feed speed | 10m/min | 15m/min |
Rapid feed speed(X/Y/Z) | 30/30/25m/min | 30/30/24m/min |
X/Y/Z axis ball screw | 3210 | 3212/3212/4012 |
Tool magazine capacity | 12T/16T(optional) | 16T |
Max.length of tool | 300mm | 240mm |
Tool change time(T-T) | 2.5s | 2.5s |
Positioning accuracy(X/Y/Z) | ±.0.005mm | ±0.010mm |
Re-positioning accuracy(X/Y/Z) | ±.0.002mm | ±0.005mm |
Machine dimension (LxWxH) | 1900x1700x2240mm | 2200x2100x2550mm |
Max.loading of worktable | 300kgs | 350kgs |
Machine weight | 3500kgs | 4100kgs |
Machine pics.
Company Profile
Professional Service
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
Company Profile
Jingjiang Fuji Technology Co., Ltd.
Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
