Machining Centre VMC850L cnc controller machining center vertical milling center
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Machining Centre VMC600L cnc controller machining center
-
VMC1580 3axis vertical machining center with cnc system from China factory
-
vertical milling center V8 high speed cnc machining center for metal
-
vertical milling center VMC850P taiwan vmc machine vmc 850 cnc milling machine center for metal working
-
cnc milling machine small VMC850L 4 axes cnc vertical machining center for metal
-
VMC1200L 4 axis cnc machining center
Product Description
Product Description
Machine features of vertical machining center:
1. The structural parts are analyzed and designed by the advanced Finite Element Analysis. It provides a detailed analysis for structural stress/strain conditions,and ensures excellent machine rigidity and lifetime stability.
2. Pre-tensioned ballscrews on X, Y, Z axes ensure accuracy and eliminate positioning error.
3. The endface of spindle stock, screw support faces and block contact faces are fully Hand-scraped to increase
machining accuracy and feeding smoothness.
4. The machine structure is constructed from high quality Meehanite cast iron and stress released to ensure great rigidity and precision.
1. The structural parts are analyzed and designed by the advanced Finite Element Analysis. It provides a detailed analysis for structural stress/strain conditions,and ensures excellent machine rigidity and lifetime stability.
2. Pre-tensioned ballscrews on X, Y, Z axes ensure accuracy and eliminate positioning error.
3. The endface of spindle stock, screw support faces and block contact faces are fully Hand-scraped to increase
machining accuracy and feeding smoothness.
4. The machine structure is constructed from high quality Meehanite cast iron and stress released to ensure great rigidity and precision.
5. Over sized column and bed, assuring extra high rigidity of machine frame.
Specification | VMC850L |
Worktable size(LxW) | 1000×500mm |
T-slot (NxWxD) | 5x18x90mm |
X/Y/Z axis travel | 800/500/500mm |
Distance from spindle center to column | 550mm |
Distance from spindle nose to worktable surface | 150-650mm |
Spindle taper | BT40 |
Spindle power | 7.5kw |
Max.spindle speed | 8000rpm |
Max.feed speed | 10m/min |
Rapid feed speed(X/Y/Z) | 32/32/30 m/min |
X/Y/Z axis ball screw | 4016 |
Tool magazine capacity | 24T |
Max.tool length | 300mm |
Tool change time(T-T) | 2.5s |
Positioning accuracy(X/Y/Z) | ±0.005mm |
Re-positioning accuracy(X/Y/Z) | ±0.003mm |
Machine size(LxWxH) | 2750×2300×2300mm |
Max.loading of worktable | 500kgs |
Machine weight | 5300kgs |
Click here get price list>>
Detailed Images
Products Recommend
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
Company Profile
