vertical milling center V8 high speed cnc machining center for metal

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Products Description

Product Application

V8 is our new type of high speed CNC machining center based on Taiwan technology, which has more advantages on operation and
capabilities compared with like products. Applied with high rigid C design on structure, it also has been done with reinforcement
on machine ribs.All the contact faces have been scraped manually, which guarantees the durability of accuracy. X/Y axes apply with
two types of rolling guide way: ball bearing and roller guide way, which is optional to customer’s requirements. Z axis applies
roller guide way, which enables the machine to be with high rigidity, low noise, and small friction. Thus the machine can do rapid
displacement and obtain circular accuracy. Equipped with air tank, the water can be drained out manually. Spindle is connected
directly, and the highest speed is 12000RPM, which are a good choice for machining of high accuracy and efficiency.

Specification	V8
Worktable
Worktable size	500×1000mm
T-slot （N×W×D）	5×18×100mm
Distance from the table to the ground	850mm
Travel
X axis travel	850mm
Y axis travel	500mm
Z axis travel	580mm
Machining range
Distance from spindle center to column front	623mm
Distance from spindle end to work table	120～700mm
Machine dimension
L×W×H	2540×2391×2700mm
Machine weight
Max. load bearing of worktable	500kgs
Machine weight	6200kgs
Spindle
Spindle hole taper	BT40
Spindle power	7.5/11kw
Max. spindle speed	12000rpm
Spindle sleeve diameter	φ140mm
Feed
Max. feed speed	15000mm/min
Rapid feed speed (X/Y/Z)	48/48/36m/min
Tool Magazine
Tool magazine capacity	24T
Max. length of tool	300mm
Tool change time	1.5s
Positioning accuracy (National standard)
Positioning accuracy (X/Y/Z)	0.008mm
Re-positioning accuracy(X/Y/Z)	0.005mm
