3 Axis Vertical Machining Center VMC1370 With CNC Controller
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
WMTCNC 4 Axis Cnc Vertical Machine Centre VMC855 Vmc Mill Machine for MetalworkingNegotiableMOQ: 1 -
VH-9 High Speed Cnc Machining Center With Good Precision From ChinaNegotiableMOQ: 1
-
Machining Centre VMC850L Cnc Controller Machining Center Vertical Milling CenterNegotiableMOQ: 1
-
Machining Centre VMC600L Cnc Controller Machining CenterNegotiableMOQ: 1
-
VMC1580 3axis Vertical Machining Center With Cnc System From China FactoryNegotiableMOQ: 1
Products Description
Product Description
CNC control system:
The system has complete and reliable interlock, safety protection and fault diagnosis and alarm functions, equipped with RS232 standard and network communication interface, and computer program control and storage, can achieve DNC processing (according to the system has differences).
The system has complete and reliable interlock, safety protection and fault diagnosis and alarm functions, equipped with RS232 standard and network communication interface, and computer program control and storage, can achieve DNC processing (according to the system has differences).
Specification |
VMC1370L |
Worktable size(LxW) |
1400×700mm |
T-slot (NxWxD) |
5x18x110mm |
X/Y/Z axis travel |
1300/700/700mm |
Distance from spindle center to column |
750mm |
Distance from spindle nose to worktable surface |
110-810mm |
Spindle taper |
BT40 |
Spindle power |
11kw |
Max.spindle speed |
8000rpm |
Max.feed speed |
10m/min |
Rapid feed speed(X/Y/Z) |
24/24/20 m/min |
X/Y/Z axis ball screw |
4512 |
Tool magazine capacity |
24T |
Max.tool length |
300mm |
Tool change time(T-T) |
2.5s |
Positioning accuracy(X/Y/Z) |
±0.008mm |
Re-positioning accuracy(X/Y/Z) |
±0.003mm |
Machine size(LxWxH) |
3200×2540×2600mm |
Max.loading of worktable |
1000kgs |
Machine weight |
8200kgs |
Details Images
Standard accessories: |
Optional accessories: |
Spindle unit8000rpm |
SYSTEM:Siemens 808D/Fanuc 0i-mf/Mitsubish |
Spindle servo motor: speed8000rpm，power11Kw |
|
GSK218 control system |
|
Taiwan 24 tools disc magazine |
|
Taiwan HIWIN screw |
|
Taiwan HIWIN linear guideway |
|
Move the hand vein |
|
Centralized automatic oil lubrication |
|
Z axis counterweight system |
|
External cooling system and water tank |
|
Simple oil-water separation device |
|
Full protection sheet metal shield and rail shield |
|
Adjustable block |
|
Tubular work lights, warning lights |
|
Rigid tapping |
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
