SP1016 Fanuc Controller CNC Gantry Machining Center High Quality Milling Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
China High Precision Double Column CNC Milling Machine GMC1015 Price
-
WMTCNC High Speed Vertical Milling Center VMC850L Cnc Milling Machine With Linear Guideway
-
3 Axis Cnc Milling Machine VMC650 Vertical Machining Center With CNC Control System
-
Vertical Cnc 5 Axis Machining Centre V10 Vertical Milling Center With High Speed
-
3 Axis Vertical Machining Center VMC1370 With CNC Controller
-
WMTCNC 4 Axis Cnc Vertical Machine Centre VMC855 Vmc Mill Machine for Metalworking
Product Description
Specification | SP1016 |
X-axis travel | 1650mm |
Y-axis travel | 1100mm |
Z-axis travel | 600mm |
Distance from spindle nose to worktable surface | 160-760mm |
Worktable size(WxL) | 1600×1000mm |
T-slots size (NxWxD) | 7-22mm |
Max. load bearing of worktable | 3000 kgs |
X/Y/Z guideway size | Roller 2-45/2-45mm,Z-axis hard guideway |
Rapid feed speed of X axis | 20000 mm/min |
Rapid feed speed of Y axis | 20000 mm/min |
Rapid feed speed of Z axis | 12000 mm/min |
Main motor power | 18.5KW |
Spindle model | BT50/Φ150 |
Motor torque | 71.7N.M |
Spindle taper | BT50 |
Blind rivets aize | P50T-2-MAS403 |
Driven type | Belt/Gear box 1：4 |
X/Y/Z linear guideway size | X/Y-axis 2-45# roller linear guideways |
X/Y/Z ball screw size | X-axis 6316,Y-axis 5016,Z-axis 5016 |
Tool magazine capacity | 24pcs |
Tool arbor | BT50 |
Max. tool dimension | Φ110/Φ220mm |
Max. length of tool | 300mm |
Max.tool weight | 18kgs |
Positioning accuracy | 0.03mm |
Re-positioning accuracy | 0.018mm |
Machine weight | 18000kgs |
Overall size (LxWxH) | 6000×4000×3900 mm |
