Carding Machine
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
Product Description
Product Description
AT202L Carding Machine
AT202L Carding Machine is used to open and card cotton, linen or chemical fibers. It repeatedly cards the curly and disordered loose fibers through metal carding needles to be parallel as well as full drafting and removal of trash. It produces sliver of specific weight and length for next drawing process. It is the part of yarn spinning system includes the opener, the carding machine, drawing frame, roving frame and ring spinning machine.
Specification
Model | AT202L |
Machine type | Right-hand |
Machine width | 1020mm |
Output capacity | (20~55)kg/h |
Cylinder diameter | 1289.2mm |
Cylinder rotation speed | 179.3r/min |
Doffer diameter | 707mm |
Doffer rotation speed | Frequency control |
Applicable fiber length | 22~150mm |
Drafting ratio | 52.5~93.7 |
Main motor power | 4KW |
Doffer motor power | 1.1KW |
Power supply | AC380V 50Hz, three-phase |
Dimensions | 4450×1930×1200mm(L×W×H) |
Weight | Approx. 5000kg |
Details and Features
★ Imported Specimen mounting tube and corkliner
★ Corkliner adopt demountable design, it’s easy to replace
★ Digital Counter display, it’s convenient to operate
Our Company
Packing&Delivery
Package | ||
Weight | 35Kg | |
Packaging Details | 1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. |
Payment
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | |||
FOB | ||||||
CFR(C&F) | 30% T/T in advance, paid the balance against copy of B/L | |||||
CIF | ||||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | |||||
West Union | Amount lower than 5000usd | |||||
Delivery Time | 7~10days after receiving payment for one container |
