Factory Manufacturer Lab Scale Carding Machine for Hemp
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
Product Description
Product Description
AT202 Laboratory Carding Machine is part of the mini spinning system. It’s mainly used in university, researching center, etc. It is used to disentangle, clean and intermix fibers to produce a continuous web or sliver suitable for subsequent processing. By passing the fibers between deferentially moving rollers covered with card clothing, it breaks up locks and unorganized clumps of fiber and then aligns the individual fibers to be parallel with each other.
Specification
Model | AT202 |
Feed in width | 400mm |
Working width | 360mm |
Max. fiber length | about 100mm |
Output | Sliver (web is optional) |
Sliver count | Max. 7g/m for cotton, 10g/m for wool |
Cylinder diameter | Φ450mm |
Doffer diameter | Φ220mm |
Licker-in diameter | Φ165mm |
Working roll diameter | Φ110mm |
Wipe roll diameter | Φ90mm |
Cylinder clothing | AC3510*2110 |
Doffer clothing | AD4335*2110 |
Working roll clothing | BW204 |
Wipe roll clothing | BT-203 |
Licker-in clothing | 1.09*4.5T |
Carding motor | 1.5kw, speed adjustable (Frequency converter control) |
Villus bucket power | 1.5KW (optional) |
Output capacity | 5~10kg/h |
Maine machine power | AC220V/380V, 50/60Hz, 2.2KW |
Dimension | 1350mm*950mm*900mm (main machine) |
900mm*900mm*1200mm (villus bucket) | |
2300mm*115mm*110mm(package) | |
Net Weight | 550kg (including the hopper) |
Gross weight | 650Kg (including the hopper) |
Details & Features
★ Imported frequency converter control, high efficiency.
★ Mini type machine, save researching cost and easy to operate and maintain.
★ Can be used for wool fiber or chemical fibers.
★ Can equipped with villus bucket or hopper to improve the quality of output sliver/web
★ It can produce web or sliver according to customer’s selection.
★ It is driven by a 2kw motor, equipped with frequency converter to adjust the running speed.
★ With full-closed protective cover.
★ Two rollers feeding.
★ The output can be net or sliver, it’s select-able
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery
Packaging | ||
Dimensions | 1400*900*1600mm | |
Weight | 200kg | |
Packaging Details | 1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. | |
Payment
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||
FOB | |||||
CFR(C&F) | |||||
CIF | |||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
West Union | Amount lower than 5000usd | ||||
West Union | |||||
Delivery Time | 7~10days after receiving payment for one container | ||||
