High Quality Elastic Material Testing Machine Made in China
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
Product Description
Product Description
AT078E Elastic Material Testing Machine is applicable for the determination of force at specific elongation, elongation at specific force, fabric elasticity and recover and plastic deformation of elastic materials, such as, spandex, spandex cored line, elastic cord, elastic ribbon, hosiery and knitted underwears. It adopts 32-bit single-chip microcomputer control with full Chinese menu display and operation. The test result includes data report, curve, graphic and form, storable and printable.
Standard
GB/T 3916 | FZ/T 70006, FZ/T 50006 | FZ/T 5007, FZ/T 73001 |
Specification
Model | AT078E |
Force measuring range | 5000cN |
Force resolution | 0.1cN |
Force accuracy | ±1% with 2%~100% of load cell |
Load resolution | 1/60000 |
Load accuracy | ≤±1%F.S |
Drawing speed | 50~1000mm/min, randomly settable |
Return speed | 50~1000mm/min, randomly settable |
Extension resolution | 0.01mm |
Max. extension | 800mm (not including clamp) |
Details & Features
1. Touch screen and large LCD display of all parameters and data
2. Be able to delete data of any test and test result can be exported to Excel document, convenient to connect with the manage software of the enterprise;
3. Analysis functions: breaking point, rupture point, stress point, yield point, initial modulus, elastic deformation and plastic deformation;
4. Safety and protection measures: limits, over-load protection, negative force protection, over-current and over-voltage protection;
5. Force calibration with digital code;
6. Unique double control technologies: controlling by main machine or PC, convenient to test and with colorful test results (data report, curve, graphic and report form);
7. Standard modulus design, convenient to maintain and update;
8. With build-in mini printer, easy to output test report.
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery
Packaging | ||
Packaging Details | 1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. | |
Payment
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||
FOB | |||||
CFR(C&F) | |||||
CIF | |||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
West Union | Amount lower than 5000usd | ||||
West Union | |||||
Delivery Time | 7~10days after receiving payment for one container | ||||
