JC-85A-550 Automatic Double-End Chamfering Machine
- 60 Set / Sets per Month
- GuangZhou/ShenZhen
- T/T Credit Card
You May Like
Product Details
| Brand Name | Chine Chern | Model Number | JC-85A-550 |
Product Description
JC-85A-550 Automatic Double-End Chamfering Machine
Characteristics:
1.Manual feeding,Automatic chamfer
2.It is suitable for chamfering steel pipe,Iron pipe,stainless steel pipe,aluminium pipe
3. Automatic clamping the pipe/bar;
4. Automatic advance of tool;
5. Chamfering angle can be changed by change the blades;
6. Automatic feeding of pipe;
7. Interior and exterior angle chamfering of tube and rod,Milling the end finish at one time.
8. The pipe chamfering machine can equably finish the process of tube end and its outer angle, inner angle at one time;
9. It adopts the variety of strap wheel to transform several rotating speed and guarantee the longest use life of blade according to different metal blade;
10. The pipe chamfering machine is easy to adjust slowness of speed to reach perfect process.
Technical Parameters:
| Model | JC-85A-550/1000 |
| Host motor | 2HP/6P*2 |
| Pipe diameter | ¢8mm- ¢ 80mm |
| Length of pipe | 80mm-550mm |
| Cutterhead | Standard cutterhead |
| Blade | Tungsten carbide throw-away blade |
| compressed air | 0.6-0.8MPA 120ml/min |
| Standard fittings | 1. one set clamps 2.one set cutter and one set blade |
| Special fittings | 1.Different sizes clamps 2.special cutter 3.automatic feeding system |
| Machine weight | 800kg |
| Machine Dimension | 2100mm×1100mm×1100mm |
ATF ------Optional
Standard Accessories:
Samples:
Package:
