JC-60SA Semi- Automatic Single-head Chamfer Machine
- ShenZhen/GuangZhou
- T/T Credit Card
You May Like
-
Alloy Stainless Steel Rod Double End Chamfer Machine
-
JC-50A-550-Double-head Automatic Chamfering Machine(hydraulic-type)
-
NC-85A-300-Double-head Automatic Chamfering Machine(hydraulic-type)
-
Pneumatic-type JC-50A-550 Double Automatic Chamfering Machine
-
JC-85A-550-Pneumatic-type Double Automatic Chamfering Machine
-
Customized Semi Automatic Big Size Pipe/bar Chamfering Machine
Product Details
| Brand Name | Chine Chern | Place of Origin | Guangdong, China | |
| Model Number | JC-60SA | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
JC-60SA Single End Steel Pipe Chamfering Machine
Main Characteristics:
1. Single side semi-automatic chamfering machine, manual feeding, automatic clamping, advancing
and retreating.
2. Special designed clamper and cutter head ensures the centerline of workpiece and knife holder
keeping at the same level, and can finish internal angle, external angle and pipe end at one time.
3. Rotate speed can be adjust according to the change of belt pulley, suit for all kinds of metal
material pipes.
4. Knife holder is designed specially and the blade is normalizing which enables adjusting knife
simply.
5. It is easy to adjust the cutting feeding speed.
Parameters:
| Model | JC-60SA(Pneumatic) |
| Host motor | 2HP/4P |
| Speed (RPM) | 90/600 2000/3560 |
| Air pressure | Mpa6-8kg/cm²,130m1/min |
| Standard cutter(Diameter) | 12mm-60mm |
| Processing range(Inner,outer and tube end surface) | Pipe diameter: 3.2mm-60mm Bar outer:6mm-38mm |
| Suitable Material | Steel pipe,Iron pipe,Stainless steel pipe,Aluminium pipe,Copper pipe |
| Machine dimension(W*D*H) | 545×655×1080mm |
| Weight | 220 |
| Accessory | 1.one set clamps 2. one tool box 3.One user manual |
Spare Parts:
Chine Chern is a top and professional hightech enterprise with more than 20 years of manufacturing experience. We are fully committed to producingtechnologically advanced pipe processing machines, such as pipe cutting machines,pipe bending machines, aluminum cutting machines, chamfering machines, etc.We emphasize development, and introduce new products into the market every year. Our products sell well in domestic and international markets, such as India, Malaysia and South Africa, and are favorably appraised by clients. We pursue the management tenet of "Quality is superior, Service is supreme, and Reputation is first", and will sincerely create and share success with all clients.

Company show:
Certificate:
*Deliver goods and install
*Training an operator
*Free warranty for one year and maintenance for lifetime
If you have any idea about it ,please feel free to contact with us and all your concerns will be received to close attention and prompt reply ,besides we will provide you with Superior Service while supplying you a suitable machine !
