JC-110SA Single Head Hydraulic Pipe Chamfering Machine
- 50 Set / Sets per Month
- ShenZhen/GuangZhou
- T/T Credit Card
- Automatic Hydraulic Single Side Chamfering Machine
- JC-85A-1000 Automatic Double End Chamfering Machine
- Full Automatic Hydraulic Double End Chamfering Machine
- Hydraulic Single End Tube/Bar Chamfering Machine
- Good Performance Double Head Chamfering Machine
- Fully Hydraulic Automatic Double Head Tube Deburring Machine
Product Details
Brand Name: | Chine Chern | Model Number: | JC-110SA |
Product Description
JC-110SA Single Head Hydraulic Chamfering Machine
Characteristics:
1. Single side semi-automatic chamfering machine, manual feeding, automatic clamping, advancing and retreating.
2. Special designed clamper and cutter head ensures the centerline of workpiece and knife holder keeping at the same level, and can finish internal angle, external angle and pipe end at one time.
3. Rotate speed can be adjust according to the change of belt pulley, suit for all kinds of metal material pipes.
4. Knife holder is designed specially and the blade is normalizing which enables adjusting knife simply.
5. It is easy to adjust the cutting feeding speed.
6.It is suitable for thick pipe and solid bar.
Parameters:
Model | JC-110SA |
Master motor | 3HP/1.5HP×2/4P |
Speed | 800/1600RPM |
Oil pressure | 0.75KW/20Lite pump work pressure 20-30kg/cm2 |
Cutterhead (3.2-16) | 12-60(Special option) |
Cutterhead (15-60) | 25-110(Standard) |
Standard fittings | 1.one set standard cutterhead 2.one set clamp |
Special fittings | 1.customized cutterhead 2. clamps of different sizes |
Suitable material | Steel pipe,iron pipe,Aluminium pipe,stainless steel pipe |
Machine Dimension(W×D×H) | 645×655×1180mm |
Net/Gross weight(KG) | 280/360 |
Parts:
Samples:
Packing :
