Hydraulic Aluminum Pipe/Bar Single Head Deburring Machine
- ShenZhen/GuangZhou
- T/T Credit Card
You May Like
-
Hydraulic Double Side Metal Round Pipe/Bar Chamfer Machine
-
Hydraulic Double Head Automatic Tube Deburring Machine
-
Single End Iron Pipe Chamfer Machine
-
JC-60SA Semi- Automatic Single-head Chamfer Machine
-
Alloy Stainless Steel Rod Double End Chamfer Machine
-
JC-50A-550-Double-head Automatic Chamfering Machine(hydraulic-type)
Product Details
| Brand Name | Chine Chern | Model Number | JC-60SA |
Product Description
Hydraulic Aluminum Pipe/Bar Single Head Deburring Machine
Characteristics:
1. The clamper and cutter head are special designed,can finish internal angle,extexternal angle and pipe end at one time.
2. Rotating speed can be adjusted according to the change of belt pulley, suit for all kinds of metal material pipes, such as iron, copper, aluminum tube parts etc.
3. Spindle’s feeding speed could be adjusted. It is easy to adjust the cutting feeding speed, it has standard speed and fast-forward speed.
4. Handing feed, automatic advance and retreat knife , speed fast , increase several times the yield.
5. This machine is designed for pipe and round rods end internal and external angles, It can both completion of the chamfer angle and shave action. It is fast and accurate.
6.In order to ensure the processing part and the centerline of the cutter remain unchanged. Clamps the mold and cutter both designed by precision. It could finish the processing symmetrical.
7.It can chamfer for work pieces of different sizes. It only change the mold or adjust the tool holder for the processing
8.Hydraulic cylinder is more stable for thick pipe and threaded rod ,Perfect process performance.
9.We can make design of cutterhead and clamp mould for different requirements.
Parameters:
| Model | JC-60SA(Hydraulic item ) |
| Host motor | 2HP/4P |
| Speed (RPM) | 90/600 2000/3560RPM |
| Oil cylinder | 0.75KW/20Lite pump,20-30kg/cm2 |
| Standard cutter(Diameter) | 12mm-60mm |
| Processing range(Inner,outer and tube end surface) | Pipe diameter: 3.2mm-60mm Bar outer:6mm-38mm |
| Suitable Material | Steel pipe,Iron pipe,Stainless steel pipe,Aluminium pipe,Copper pipe |
| Machine dimension(W*D*H) | 545×655×1080mm |
| Weight(KG) | 230kg |
| Accessory | 1.one set clamp mould 2. one tool box 3.One user manual |
Accessories
Machie Photo & Packing :
Samples:
Picture:
Company Profiles :
with decades hard work and accumulated experiences, We have acquired fourty invention
patent,Utility model and appearance patent.Meanwhile, We have passed ISO9001:2008 quality system certificate, Government-issued Guangdong Province private technology enterprises, high-
tech enterprises, private enterprises and other honors.
The products include Super hard metal bar cold saw machine series, Chipless metal pipes circular saw machine series,Copper aluminum non-ferrous high-speed precision circular saw machine series,Metal pipe/bar end chamfer machine series,Circular saw blade sharpening machine series,Automatic pipe bending and forming Machine series , Six categories eighty models , Also provide customized complex process
Machine , all kinds of circular saw blade . Wide Application range contains Nautical
aviation and aerospace industry, military industry, high-speed rail and rail transportation
industry, auto industry, precision parts, medical and fitness equipment industry, mechanical and electrical and electronic industry, lighting and furniture decoration forty industries .
