Steel Round Pipe/Bar Single Side Chamfer Machine
- ShenZhen/GuangZhou
- T/T Credit Card
You May Like
-
Hydraulic Aluminum Pipe/Bar Single Head Deburring Machine
-
Hydraulic Double Side Metal Round Pipe/Bar Chamfer Machine
-
Hydraulic Double Head Automatic Tube Deburring Machine
-
Single End Iron Pipe Chamfer Machine
-
JC-60SA Semi- Automatic Single-head Chamfer Machine
-
Alloy Stainless Steel Rod Double End Chamfer Machine
Product Details
| Brand Name | Chine Chern | Place of Origin | Guangdong, China | |
| Model Number | JC-60SA | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Steel Round Pipe/Bar Chamfer/Beveling Machine
Main Features:
1: Semi-automatic chamfering machine; 2: Feeding tube by manual, blade forward and back automatically, due to the high speed, the production capacity increase double more; 3: This machine is good at chamfering inner and out angle of circular tube or circular rod, chamfering and deburring can be finished at one time in fast speed and accuracy; 4: Clamping device and knife holder are designed precision and accurately, which ensure the center line of workpiece and knife holder keep at the same level;
5: Knife holder as designed specially and the blade is normalizing which enable adjusting knife simply.
6.Special cutterhead can be customised as per request.
7.Feed speed is adjustable by belt pulley as per materials thickness.It can achieve the perfect performance.
8.The clamp mould is correspondence with different out diameter of pipes ,It is simple to change and maintain.
Technical Parameters:
| Model | JC-60SA(Pneumatic) |
| Host motor | 2HP/4P |
| Speed (RPM) | 90/600 2000/3560 |
| Air pressure | Mpa6-8kg/cm²,130m1/min |
| Standard cutter(Diameter) | 12mm-60mm |
| Processing range(Inner,outer and tube end surface) | Pipe diameter: 3.2mm-60mm Bar outer:6mm-38mm |
| Suitable Material | Steel pipe,Iron pipe,Stainless steel pipe,Aluminium pipe,Copper pipe |
| Machine dimension(W*D*H) | 670×850×1130mm |
| Weight(KG) | 220 |
| Accessory | 1.one set clamps 2. one tool box 3.One user manual |
Spare parts & Samples:
Samples:
Package:
