Home > Products > Automatic metal bar/pipe end chamfering machine > Automatic Single End Tube Deburring Machine
Automatic Single End Tube Deburring Machine
- ShenZhen/GuangZhou
- T/T Credit Card
You May Like
Product Details
| Brand Name | Chine Chern | Model Number | JC-60SA |
Product Description
Automatic single end tube deburring machine
Features:
1. Single side semi-automatic chamfering machine, manual feeding, automatic clamping, advancing and retreating.
2. Special designed clamper and cutter head ensures the centerline of workpiece and knife holder keeping at the same level, and can finish internal angle, external angle and pipe end at one time.
3. Rotate speed can be adjust according to the change of belt pulley, suit for all kinds of metal material pipes.
4. Knife holder is designed specially and the blade is normalizing which enables adjusting knife simply.
5. It is easy to adjust the cutting feeding speed.
Parameters:
| Model | JC-60SA(Hydraulic) |
| Host motor | 2HP/4P |
| Speed (RPM) | 90/600 2000/3560 |
| Hydraulic pump | 0.75KW/20Lite pump,20-30kg/cm2 |
| Standard cutter(Diameter) | 12mm-60mm |
| Processing range(Inner,outer and tube end surface) | Pipe diameter: 3.2mm-60mm Bar outer:6mm-38mm |
| Suitable Material | Steel pipe,Iron pipe,Stainless steel pipe,Aluminium pipe,Copper pipe |
| Machine dimension(W*D*H) | 545×655×1080mm |
| Weight(KG) | 220KGS |
Machine details :
Structures :
Finish:
Package :
