MC-275A manual feeding brass tube cutting machine
- 1000 per Month
- T/T Credit Card
- MC-275A Steel pipe cold cutter manual
- MC-315A manual angle cut 45 degree band saw machine
- Automatic servo feeding hydraulic cnc pipe cutting machine with high accurancy
- MC-350CNC-Y Automatic cnc hydraulic stainless steel pipe cutting machine for tube brand circular sawing with promotion price
- MC-350CNC Automatic high accurancy tube cutting machine for pipe cold sawing by Mitsubishi servo motor feeding
- MC-275B semi auto pneumatic steel pipe cutting machine with high speed
Product Details
Brand Name: | CARE |
Product Description
MC-275A manual feeding brass tube cutting machine
Main specification
1.The cutting machine use the block-drive turbine vortex .
2. Small nose, small shock, without dust pollution, no thorns.
3. Tangent plane is fluent,good quality internal and external incisions.High priduction and precision of saw cutting.
4. Vertical slideway for advance and retreat blade up and down.
5. Cutting feed is steady and cutting tools are of long use life.
6.Cooling and lubricante system ensure the cutting surface and prolong the life of saw blades.
7. Advance of tool adopts manual mode, the cutting machine's head can rotate 45 degree left and right.
Cutting capacity
Max cutting and sawing capacity ( mild steel)
Machine model | MC-275 Series | MC-315 Series | ||
Cutting direction | 90 degree | 45 degree | 90 degree | 45 degree |
Hollow pipe | 80 | 60 | 100 | 80 |
Hollow square steel | 60×60 | 45×45 | 90×90 | 80×80 |
Hollow rectangular pipe | 60×80 | 45×60 | 80×90 | 80×80 |
Solid rectangular steel | 60×60 | 45×45 | 90×90 | 80×80 |
Solid shafting | 38 | 25 | 55 | 45 |
Solid square steel | 38 | 25 | 50 | 40 |
Technical parameters
Machine model | MC-275 Series | MC-315 Series | ||
Main pump | two-speed electric motor 2/2.4kw | two-speed electric motor 2/2.4kw | ||
Principle axis | RPM60/120 | RPM60/120 | ||
Applicable saw blades | OD 250/275 mm | OD 250/275/315 mm | ||
Cooling pump | 90W | 90W | ||
Air compression | 0.4~0.6MPa | 0.4~0.6MPa | ||
Machine weight | Type A | Type B | Type A | Type B |
180 | 190 | 200 | 210 |
Machine photo
To know more information, please contact us at any time.
