Product Details
| Brand Name: | CARE |
Product Description
High speed 45 degree pneumatic copper pipe cutter machine, 45 degree cutting machines for steel pipe tube
Main specification
1.Manual feeding, Automatic clamping and Cutting
2.Can be realized angle cutting
3.Material Available: Carbon Steel,Stainless Steel,Copper,Aluminum...
4.Cutting Shape Available: Round,Square,Rectangle,Solid bar,other profiles...
5.Small Noisy
6.Good cutting quality for tube internal and external without burs.
7.Water cooling and lubricate system prolongs the life of machine and saw blade.
8.Good mechancial parts ensure machine runs in high stability.
9.CE, ISO9001 Certification
Max cutting and sawing capacity ( mild steel)
Machine model | MC-275 Series | MC-315 Series | ||
Cutting direction | 90 degree | 45 degree | 90 degree | 45 degree |
Hollow pipe | 80 | 60 | 100 | 80 |
Hollow square steel | 60×60 | 45×45 | 90×90 | 80×80 |
Hollow rectangular pipe | 60×80 | 45×60 | 80×90 | 80×80 |
Solid rectangular steel | 60×60 | 45×45 | 90×90 | 80×80 |
Solid shafting | 38 | 25 | 55 | 45 |
Solid square steel | 38 | 25 | 50 | 40 |
Technical parameters
Machine model | MC-275 Series | MC-315 Series | ||
Main pump | two-speed electric motor 2/2.4kw | two-speed electric motor 2/2.4kw | ||
Principle axis | RPM60/120 | RPM60/120 | ||
Applicable saw blades | OD 250/275 mm | OD 250/275/315 mm | ||
Cooling pump | 90W | 90W | ||
Air compression | 0.4~0.6MPa | 0.4~0.6MPa | ||
Machine weight | Type A | Type B | Type A | Type B |
180 | 190 | 200 | 210 | |
Machine photo
Automatic cnc pipe cutting machines
