MC-350CNC Automatic Servo Feeding Circular Steel Tube Cold Cutting Saw Machine Price
- T/T Credit Card
You May Like
-
Metal Circular Saw Machine MC275A, Manual Key Cutting Machines, Manual Pipe Bevel Machine Cutter
-
Automatic Stainless Pipe Cutter Machine, Hydraulic Metal Circular Sawing Machine, Stainless Steel Tube Cutting Machine
-
MC-275A Manual Small Pipe Cutting Machine, ss Tube Cutter, Pipe Thread Cutting Machine
-
Automatic Hydraulic Copper Pipe Vertical 90 Degree Band Saw Machine, Steel Tube Cutting Machine
-
MC-350CNC Automatic Steel Tube Cutting Machine, Plc Control Automatic Saw Machine, Multi-blade Circular Saw
-
MC-350CNC Automatic Cnc Pipe Cutting Machine, Cnc Stainless Steel Tube Cutting Machine, Carbon Steel Tube Cutting Machine
Product Details
| Brand Name | CARE |
Product Description
MC-350CNC Automatic servo feeding Circular steel tube cold cutting saw machine price
Main specification
1.The machine adopt man-machine interface, PLC control or Single-chip computerl, operating simple.
2.Using HSS saw web:250-400mm,Standard saw web is Φ350mm.
3.Special design, multiple gears, suitable for heavy cutting ,precision and stability.
4.Feeding, clamping, cutting off with automatic circulation.
5.PLC or Single-chip control, can choose many times feeding(One time 6-1500mm).
6.Using cooling fluid. cooling motor 0.09KW to ensure the smooth workpiece section.
7.Using hydraulic pressure oil.
8.Using special clamp mold, several pipes could be cut together according to the different size of pipe diameter.
Technical parameter
Specification/Model | MC-350CNC | ||
sawing scale | Applicable sawblade 350-400mm | ||
rectangle pipe | 120mm x 90mm | ||
square pipe | 110mm×110mm | ||
round pipe | 125mm | ||
round bar | 75mm | ||
square bar | 65mm×65mm | ||
Size | 2400×1100mm×1700mm | ||
Weight | 1000kg | ||
Main motor(KW) | 2.2KW | ||
Main shaft speed(RPM) | 44/22 | ||
Feeding length Standard | 5-1500mm*time after time | ||
Oil motor system | 3.5KW motor,18L pump | ||
Cooling system | 0.09KW motor | ||
Machine photo
Manual&semi-automatic pipe cutting machine
