DN2000 Carbon Steel Turbine Butterfly Valve
- Shanghai Port or Ningbo Port
- T/T Money Gram
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Butterfly | |
| Pressure | Medium Pressure | Power | Manual | |
| Material | Other, Carbon Steel | Temperature of Media | Normal Temperature | |
| Media | Water | Port Size | DN2000 mm | |
| Place of Origin | Chongqing, China | Model Number | N/A | |
| Brand Name | HS |
Product Description
Specifications
Turbine Butterfly Valve:1. Diameter: 100-2000 mm
2. Pressure: 0.6-2.5 Mpa
3. Connection: Flange
4. OEM, ODM Accepted
Turbine Butterfly Valve:
DN2000 Carbon Steel Turbine Butterfly Valve:
1. Product Brief Introduction:
(1). Model: D373H-16C-DN1600
(2). Material: Carbon Steel
(3). Media: Water, Air, Gas, Oil, Weak Corrosivity
(4). Type: Two General Through
(5). Connection: Wafer Type
(6). Pressure: Normal Pressure
(7). Drive Way: Hand Drive
(8). Diameter: 1600
(9). Working Temperature: Normal Pressure
(10). Suitable Temperature: 29°C~425°C
(11). Working Pressure: 0.6 Mpa, 1.0 Mpa, 1.6 Mpa, 2.5 Mpa
(12). Drive Way: Electric Drive, Air Drive, Hydraulic Drive, Worm Gear Drive
2. Product Size:
Nominal Diameter | Flange Size and Bolt Type | |||
1.0MPa | 1.6MPa | 2.5MPa | 4.0MPa | |
D1 | D1 | D1 | D1 | |
100 | 180 | 180 | 190 | 190 |
125 | 210 | 210 | 220 | 220 |
150 | 240 | 240 | 250 | 250 |
200 | 295 | 295 | 310 | 320 |
250 | 350 | 355 | 370 | 385 |
300 | 400 | 410 | 430 | 450 |
350 | 460 | 470 | 490 | 510 |
400 | 515 | 525 | 550 | 585 |
450 | 565 | 585 | 600 | 610 |
500 | 620 | 650 | 660 | 670 |
600 | 725 | 770 | 770 | 795 |
700 | 840 | 840 | 875 |
|
800 | 950 | 950 | 990 |
|
900 | 1050 | 1050 | 1090 |
|
1000 | 1160 | 1170 | 1210 |
|
1200 | 1380 | 1390 | 1420 |
|
1400 | 1590 | 1590 | 1640 |
|
1600 | 1820 | 1820 | 1860 |
|
1800 | 2020 | 2020 | 2070 |
|
2000 | 2230 | 2230 | 2300 |
|
3. DN2000 Carbon Steel Turbine Butterfly Valve Drawing Picture:
4. DN2000 Carbon Steel Turbine Butterfly Valve Sample Picture:
