Home > Industrial Equipment & Components > Valve > Ball Valve > Flange Type Soft Sealing Industry Gate Valve

Flange Type Soft Sealing Industry Gate Valve

US$ 1 - 10 MOQ: 1 Set

Key Specifications

Get Latest Price

Standard or Nonstandard:

Standard

Structure:

Gate

Pressure:

Medium Pressure

Contact Supplier Request Quote Chat Now

Chongqing Hi-Sea Marine Equipment Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port or Ningbo Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard or Nonstandard Standard

Structure Gate

Pressure Medium Pressure

Power Manual

Material Casting

Temperature of Media Normal Temperature

Media Water

Port Size DN500 mm

Place of Origin Chongqing, China

Model Number N/A

Brand Name HS

Specifications

Industry Gate Valve:
1. Standard: API, DIN
2. Diameter: DN40-500 mm
3. Sealing: Soft Sealing
4. Connection: Flange

Industry Gate Valve:

Flange Type Soft Sealing Industry Gate Valve:

Detailed Information:

1. Model: Z45X-10/16QB

2. Type: Straight-through type

3. Main Part Material: Nodular Cast Iron

4. Flow Way: Double Way

5. Sealing: Soft Sealing

6. Media: Water

7. Standard: API (ANSI), DIN

8. Working Temperature: Nomal Temperature

9. Pressure: Low Pressure

10. Application: Inflow

11. Drive Way: Hand Drive

12. Nominal Diameter: DN40-DN500 mm

13. Connection: Flange

Application:

Industry Field, Urban water supply and drainage pipe network, high-rise residential area, petrolem and gas, power station, environmental, mine, paper, fermentatio.

Industry Gate Valve Specification: (See the Chart):

Nominal Diameter(DN)	Structure Length	H	Bolt
			10Kg				16Kg				Weight kg
			Screw Hole Center Circle Diameter D	Bolt Hole Diameter	Quantity	Thread Type	Screw Hole Center Circle Diameter D	Bolt Hole Diameter	Quantity	Thread Type
40	165	170	110	19	4	M16	110	19	4	M16	7
50	178	185	125	19	4	M16	125	19	4	M16	9
65	190	205	145	19	4	M16	145	19	4	M16	11
80	203	310	160	19	8	M16	160	19	8	M16	16
100	229	340	180	19	8	M16	180	19	8	M16	27
150	267	430	240	23	8	M20	240	23	8	M20	50
200	292	520	295	23	8	M20	295	23	12	M20	80
250	330	545	350	23	12	M20	355	28	12	M24	120
300	356	660	400	23	12	M20	410	28	12	M24	160
400	406	915	515	28	16	M24	525	31	16	M27	350
500	457	1110	620	28	20	M24	650	34	20	M30	585
