UT107 Handheld Automotive Multi-Purpose Meters Ac/dc Voltage Current Tester Multimeter

FOB Price

US$ 15 - 20 / Piece

10 Pieces(Min. Order)

Port Shenzhen
Payment TermsT/T Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	UNI-T
Model Number	UT107	Measuring Current Range	200mA/10A
Measuring Voltage Range	200mV/2V/20V/1000V	Measuring Resistance Range	200Ω/2kΩ/20kΩ/200kΩ/20MΩ
Measuring Capacitance Range	100uF	Measuring Inductance Range	1000V/1000V
Operating Temperature	-40°C - 1000°C	Dimensions	179mm * 88mm * 39mm

Product Description

UT107 Handheld Automotive Multi-Purpose Meters ac/dc Voltage Current Tester Multimeter

Introduction

UT105 Meter is a 1999 count digital multimeter manual range cars. It has a large screen, full-featured symbol display and input connections prompt, full scale overload protection and unique design, making it more secure and better performance of electrical instruments.

This instrument can be used to measure: AC and DC voltage, DC current, resistance, diodes, circuit continuity and the car speed and angle closure.

Specification

Specifications	Range	Best Accuracy
Model		UT105	UT106	UT107
DC Voltage (V)	200mV/2V/20V/200V/1000V	±(0.5%+5)	±(0.5%+2)
DC Voltage (V)	200mV/2V/20V/1000V			±(0.5%+2)
AC Voltage (V)	2V/20V/200V/750V	± (0.8%+5)
AC Voltage (V)	200V/750V		± (0.8%+5)	± (0.8%+5)
DC Current (A)	200mA/10A	± (0.8%+5)	± (0.8%+5)	± (0.8%+5)
Resistance (Ω)	200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ	± (0.8%+5)	± (0.8%+5)
Resistance (Ω)	200Ω/2kΩ/20kΩ/200kΩ/20MΩ			± (0.8%+5)
Frequency (Hz)	2kHz		±(2%+5)	±(2%+5)
Temperature (°C)	-40°C - 1000°C		±(2%+8)	±(2%+8)
Features
Display Count		2000	2000	2000
Manual Range		√	√	√
Battery Test	12V			±(3%+5)
Duty Cycle	1%-90%			±(4%+5)
Diode		√	√	√
Continuity Buzzer		√	√	√
Low Battery Indication		√	√	√
Data Hold		√	√	√
Input Protection		√	√	√
Input Impedance for DCV	Around 10MΩ	√	√	√
Dwell	4CYL/6CYL/8CYL	±(3%+5)	±(3%+5)	±(3%+5)
Tach	4CYL/6CYL/8CYL	±(3%+5)	±(3%+5)	±(3%+5)
General Characteristic
Power	9V Battery(6F22) (not included)
LCD Size	60mm * 54 mm
Product Color	Red and Grey
Product Net Weight	351g(Including Holster)
Product Size	179mm * 88mm * 39mm
Standard Accessories	UT105-Battery, Test Lead, Holster
Standard Accessories	UT106/UT107-Battery, Test Lead, Holster, Point Contact Temperature Probe
Standard Individual Packing	Gift Box, English Manual
Standard Quantity Per Carton	40 PCs
Standard Carton Measurement	645mm450mm340mm (0.0987 CBM Per Standard Carton)
Standard Carton Gross Weight	24.6 Kg

Accessory

1. Battery,(not included)
2. Test Lead,
3. Holster

4. Point Contact Temperature Probe
