Insulation Resistance Tester UT513 Megger Tramegger 500V/1000V/2500V/5000V USB Interface
US$ 150 - 210
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT513
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Intelligent Digital Double Clamp Phase Meter UNI-T UT265B Auto Range Multimeter AC Voltmeter AmmeterUS$ 250 - 300MOQ: 1 Piece -
60A True RMS Mini Clamp Meters UNI-T UT211B Multimeter Ohm DC AC Voltmeter AmmeterUS$ 55 - 75MOQ: 5 Pieces
-
UNI-T UT181A True RMS Datalogging Multimeters Handheld Color Oscilloscope Digital Multimeter 100kHz BrandwidthUS$ 300 - 330MOQ: 1 Piece
-
UNI-T UT70A Modern Digital Multi Purpose Meter LCD Handheld Multimeter Multi Use Tester ac dc Volt Amp Ohm Capacitance TesterUS$ 30 - 50MOQ: 1 Piece
-
UNI-T UT61A Modern Digital Multimeter LCD Handheld Mini Multi Purpose Meter ac dc Volt Amp Ohm Capacitance TesterUS$ 20 - 30MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT513
Display Type
Digital Only
Measuring Range
1000Ω
Testing Voltage
500V/1000V/2500V/5000V
Dimensions
202mm*155mm*94mm
Insulation Resistance Tester UT513 megger tramegger 500V/1000V/2500V/5000V USB Interface
Introduction
UT513 is an intelligent insulation test instruments, the whole design of the circuit design using computer technology as the core, LSI and digital circuits combined with powerful measurement and data processing software, complete insulation resistance, voltage, low resistance and other parameters measured, stable performance and easy operation.
For on-site power equipment and power supply line measurement and inspection, maintenance and repair of electrical equipment is the ideal tool. Also used in metallurgy, communications, manufacturing, petroleum, defense, power, chemical, and other industries circuit measurement and maintenance.
Specification
| Specification | Range | Best Accuracy | |||
| Model | UT511 | UT512 | UT513 | ||
| Insulation Resistance(Ω) | Test Voltage | 100V/250V/500V/1000V | 0%-20% | ||
| 500V/1000V/1500V/2500V | 0%-20% | ||||
| 500V/1000V/2500V/5000V | 0%-20% | ||||
| 100V | 0.1MΩ~500MΩ | ±(3%+5) | |||
| 250V | 0.5MΩ~2GΩ | ±(3%+5) | |||
| 500V | 1MΩ~4GΩ | ±(3%+5) | |||
| 1MΩ~5GΩ | ±(3%+5) | ||||
| 1MΩ~20GΩ | ±(3%+5) | ||||
| 1000V | 2MΩ~10GΩ | ±(3%+5) | ±(3%+5) | ||
| 2MΩ~40GΩ | ±(5%+5) | ||||
| 1500V | 5MΩ~20GΩ | ±(3%+5) | |||
| 2500V | 10MΩ~100GΩ | ±(3%+5) | |||
| 5MΩ~100GΩ | ±(3%+5) | ||||
| 5000V | 10MΩ~1000GΩ | ±(3%+5) | |||
| Short Circuit Current | <2mA | <1.8mA | <1.8mA | ||
| DC Voltage (V) | 1000V | ±(2%+3) | |||
| 600V | ±(2%+5) | ±(2%+5) | |||
| AC Voltage (V) | 750V | ±(2%+3) | |||
| 600V | ±(2%+5) | ±(2%+5) | |||
| Low Resistance (Ω) | 0.1Ω-999.9Ω | ±(1%+3) | |||
| Features | |||||
| Display Count | 9999 | 9999 | 9999 | ||
| Auto Range | √ | √ | √ | ||
| Auto Power Off | √ | √ | √ | ||
| Low Battery Indication | √ | √ | √ | ||
| Data Logging | 18 | 18 | 18 | ||
| Comparison | √ | √ | √ | ||
| Polarization Index(PI) | √ | √ | √ | ||
| Dielectric Absorption (DAR) | √ | √ | √ | ||
| USB Interface | √ | √ | |||
| LCD Backlight | √ | √ | √ | ||
| Analogue Bar Graph | 30 | 30 | 30 | ||
| Over Range Warning | √ | √ | √ | ||
| High Voltage Indication | √ | √ | √ | ||
| Timer | Around 30 minutes | √ | |||
| Around 15 minutes | √ | √ | |||
| General Characteristic | |||||
| Power | 1.5V Alkaline Batteries(LR14)*8 | ||||
| LCD Size | 123mm * 58mm | ||||
| Product Color | Red & Grey | ||||
| Product Net Weight | UT511-1.2Kg, UT512-1.8Kg, UT513-2Kg | ||||
| Product Size | 202mm*155mm*94mm | ||||
| Standard Accessories | UT511 - 2PCs of One Plug Test Lead to One Alligator Clip(Black and Green), 1 PC of Two Plugs Test Lead to One Alligator Clip(Red), Batteries, Tool Box. | ||||
| UT512/UT513- 2PCs of One Plug Test Lead to One Alligator Clip(Black and Green),1 PC of Two Plugs Test Lead to One Alligator Clip(Red), Batteries, Tool Box, USB Cable,PC Software CD, Power Adaptor | |||||
| Standard Individual Packing | Gift Box, English Manual | ||||
| Standard Quantity Per Carton | 4 PCs | ||||
| Standard Carton Measurement | 525mm * 335mm * 345mm (0.061CBM Per Standard Carton) | ||||
| Standard Carton Gross Weight | UT511-13Kg, UT512-18Kg, UT513-19Kg | ||||
| Optional Accessories* | |||||
| Power Adaptor(UT511 only) | |||||
Accessory
2PCs of One Plug Test Lead to One Alligator Clip(Black and Green),
1 PC of Two Plugs Test Lead to One Alligator Clip(Red),
Batteries,
Tool Box,
USB Cable,
PC Software CD,
Power Adaptor
