Home > Instruments & Meters > Meter for Electricity > Multimeter > General Digital Multimeters UNI-T UT39B AC DC Voltage and Current Manual Range Handheld Portable Multimeter

General Digital Multimeters UNI-T UT39B AC DC Voltage and Current Manual Range Handheld Portable Multimeter

Name: General Digital Multimeters UNI-T UT39B AC DC Voltage and Current Manual Range Handheld Portable Multimeter
Brand: UNI-T
SKU: 130761633
Availability: InStock

General Digital Multimeters UNI-T UT39B AC DC Voltage and Current Manual Range Handheld Portable Multimeter thumbnail-1

General Digital Multimeters UNI-T UT39B AC DC Voltage and Current Manual Range Handheld Portable Multimeter thumbnail-2

General Digital Multimeters UNI-T UT39B AC DC Voltage and Current Manual Range Handheld Portable Multimeter photo-1

General Digital Multimeters UNI-T UT39B AC DC Voltage and Current Manual Range Handheld Portable Multimeter photo-2

US$ 10 - 16 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

UNI-T

Model Number:

UT39B

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name UNI-T

Model Number UT39B

Measuring Current Range 20μA-10A

Measuring Voltage Range 200mV-1000V

Measuring Resistance Range 200Ω-200MΩ

Measuring Capacitance Range 2μF

Measuring Inductance Range none

Operating Temperature -40 °C - 1000°C

Dimensions 172mm*83mm*38mm

General Digital Multimeters UNI-T UT39B AC DC Voltage and Current Manual Range Handheld Portable multimeter

Introduction

UT39 series are 3 1/2 digit digital multimeter to manually switch range. Full range overload protection and unique design, making it more superior performance of electrical instruments.

Suitable for measuring smelting, telecommunications, manufacturing, oil, defense, electricity, chemical and other industries, it is the ideal tool circuit, electrical equipment maintenance and repair.

Specification

Specification	Range	Best Accuracy
Model		UT39A	UT39B
DC Voltage (V)	200mV/2V/20V/200V/1000V	±(0.5%+1)	±(0.5%+1)
AC Voltage (V)	2V/20V/200V/750V	±(0.8%+3)	±(0.8%+3)
DC Current (A)	20μA/200μA/2mA/20mA/200mA/10A	±(0.8%+1)
DC Current (A)	20μA/2mA/20mA/200mA/10A		±(0.8%+1)
AC Current (A)	200μA/20mA/200mA/10A	±(1%+3)
AC Current (A)	2mA/200mA/10A		±(1%+3)
Resistance (Ω)	200Ω/2KΩ/20KΩ/200KΩ/2MΩ/200MΩ	±(0.8%+1)
Resistance (Ω)	200Ω/2KΩ/20KΩ/2MΩ/20MΩ/200MΩ		±(0.8%+1)
Capacitance (F)	2μF	±(4%+3)
Capacitance (F)	2nF/200nF/20μF		±(4%+3)
Features
Display Count		1999	1999
Manual Range		√	√
Diode		√	√
Transistor		√	√
Auto Power Off		√	√
Continuity Buzzer		√	√
Low Battery Indication		√	√
Data Hold		√	√
Input Impedance for DCV	Around 10MΩ	√	√
General Characteristic
Power	9V Battery(6F22)
LCD Size	61mm×32mm
Product Color	Red and Grey
Product Net Weight	310g (Including Holster)
Product Size	172mm×83mm×38mm
Standard Accessories	Battery, Test Lead,Holster
Standard Individual Packing	Gift Box, English Manual
Standard Quantity Per Carton	40 PCs
Standard Carton Measurement	598mm×418mm×340mm (0.085 CBM Per Standard Carton)
Standard Carton Gross Weight	21Kg
