UNI-T UT70A Modern Digital Multi Purpose Meter LCD Handheld Multimeter Multi Use Tester ac dc Volt Amp Ohm Capacitance Tester
US$ 30 - 50
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
ut70a
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UT61A Modern Digital Multimeter LCD Handheld Mini Multi Purpose Meter ac dc Volt Amp Ohm Capacitance TesterUS$ 20 - 30MOQ: 1 Piece -
UNI-T UT151C Modern Digital Multimeter LCD Handheld Mini Multipurpose Meter ac dc Volt Amp Ohm Capacitance TesterUS$ 1 - 20MOQ: 1 Piece
-
True RMS Digital Multimeters UNI-T UT139C AC DC Voltage and Current Auto Range Handheld MultimeterUS$ 18 - 38MOQ: 1 Piece
-
True RMS Digital Multimeters UNI-T UT139B AC DC Voltage and Current Auto Range Handheld MultimeterUS$ 15 - 30MOQ: 1 Piece
-
True RMS Digital Multimeters UNI-T UT139A AC DC Voltage and Current Auto Range Handheld MultimeterUS$ 15 - 30MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
ut70a
Measuring Current Range
20mA- 10A
Measuring Voltage Range
2-0mV-1000V
Measuring Resistance Range
200Ω - 200MΩ
Measuring Capacitance Range
20nF/100μF
Measuring Inductance Range
2mH-20H
Operating Temperature
-40 °C - 1000°C
Dimensions
195mm*90mm*40mm
UNI-T UT70A Modern Digital Multi Purpose Meter LCD Handheld Multimeter Multi Use Tester ac dc Volt Amp Ohm Capacitance Tester
Introduction
UT70A is a handheld electric bridge multimeters, the advanced product design, functional and stable performance, institutional trendy, large screen display, can be used to measure AC and DC voltage and current, resistance, capacitance, inductance, temperature, frequency, diode forward buck, transistor hFE and sound off,; logic level and has a data hold and maximum hold function (in low light places also provide backlight screen)
Specification
| Specifications | Range | Best Accuracy | |
| Model | UT70A | UT70B | |
| DC Voltage (V) | 200mV/2V/20V/200V/1000V | ±(0.5%+1) | |
| 400mV/4V/40V/400V/1000V | ±(0.8%+1) | ||
| AC Voltage(V) | 200mV/2V/20V/200V/750V | ±(0.8%+3) | |
| 4V/40V/400V/750V | ±(1%+5) | ||
| DC Current (A) | 20mA/2mA/200mA/10A | ±(0.8%+1) | |
| 400mA/4000mA/40mA/400mA/10A | ±(1%+2) | ||
| AC Current (A) | 20mA/2mA/200mA/10A | ±(1%+3) | |
| 400mA/4000mA/40mA/400mA/10A | ±(1.5%+5) | ||
| Resistance (Ω) | 200Ω/2kΩ/20kΩ/200MΩ/2MΩ/20MΩ/200MΩ | ±(0.8%+1) | |
| 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ | ±(1%+2) | ||
| Capacitance (F) | 20nF/200nF/2μF/100μF | ±(2.5%+5) | |
| 4nF/40nF/400nF/4μF/40μF/400μF/4μF/40μF | ±(4%+3) | ||
| Inductance | 2mH/20mH/200mH/20H | ±(2%+10) | |
| Frequency | 2kHz~10MHz | ±(0.1%+3) | |
| 4kHz/40kHz/400kHz/4MHz/40MHz/400MHz | ±(0.1%+3) | ||
| Temperture(°C) | -40℃~1000℃ | ±(1%+3) | ±(1%+3) |
| Temperture(°F) | -40℉~1832℉ | ±(1%+4) | ±(1%+4) |
| RPM | 40kRPM | ±(0.1%+3) | |
| Features | |||
| Fused 10A Range | √ | √ | |
| Diode | √ | √ | |
| Transistor | √ | ||
| Continuity Buzzer | √ | √ | |
| Relative measurement | √ | ||
| Relative Mode | TTL | √ | |
| Full Icon Display | √ | √ | |
| Sleep Mode | √ | √ | |
| Low Battery Display | √ | √ | |
| Input Impedance for DC Voltage Measurement | 10MΩ | √ | √ |
| Max/Min Mode | √ | ||
| Peak Hold | √ | ||
| Data Hold | √ | √ | |
| Display Backlight | √ | √ | |
| Auto Ranging | √ | √ | |
| Max. Display | 1999 | 3999 | |
| RS232 | √ | ||
| Analog Bar Graph | 41 | √ | |
| General Characteristic | |||
| Power | 9V Battery (6F22) | ||
| LCD Size | 62mm×53mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 600g (including holster) | ||
| Product Size | 195mm×90mm×40mm | ||
| Standard Accessories | UT70A-Test Lead, Battery, English Manual, Point Contact Temperature Probe, Test Clip, Multi-Purpose Socket, Holster | ||
| UT70B-Test Lead, Battery, English Manual, Point Contact Temperature Probe, Test Clip, RS232C Interface Cable, Software, Holster | |||
| Standard Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 20Pcs | ||
| Standard Carton Measurement | 535mm×362mm×385mm(Around 0.074 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | UT70A-22.7kg,UT70B-20kg | ||
| Optional Accessories* | Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2), Carrying Bag | ||
Accessory
1. Test Lead,
2. Battery,
3. English Manual,
4. Point Contact Temperature Probe,
5. Test Clip,
6. Multi-Purpose Socket,
7. Holster.
8. Clip-On Test Lead Light (UT-TL), *
9. Built-In Test Lead Light (UT-L1), *
10. Built-In Test Lead Light Plus (UT-L2), *
11. Carrying Bag*
