Product Details
| Place of Origin: | Guangdong, China | Brand Name: | UNI-T | Model Number: | UT71E |
| Measuring Current Range: | 200μA - 10A | Measuring Voltage Range: | 200mV - 1000V | Measuring Resistance Range: | 200Ω - 20MΩ |
| Measuring Capacitance Range: | 20nF - 20mF | Measuring Inductance Range: | none | Operating Temperature: | -40 °C - 1000°C |
| Dimensions: | 200mm * 93mm * 40 mm |
Product Description
Intelligent Digital Multimeters UNI-T UT71E Automotive Palm Size Multi-Purpose Meter LCD Voltmeter Ammeter Ohmmeter Auto Range
Introduction
T71 Series auto range True RMS digital multimeter with analog bar graph shows a full-featured, full-range overload protection and unique design, making performance more superior precision electrical measuring instruments.
Suitable for: metallurgy, electronics, telecommunications, manufacturing, petroleum, defense, power, chemical and other industries and major colleges. Also used to solve electronics, factory automation, power distribution and electromechanical equipment of complex issues.
Specification
| Specifications | Range | Best Accuracy | ||
| Model | UT71C | UT71D | UT71E | |
| DC Voltage (V) | 400mV/4V/40V/400V/1000V | ±(0.025%+5) | ±(0.025%+5) | ±(0.025%+5) |
| AC Voltage (V) | 4V/40V/400V/1000V | ±(0.4%+30) | ±(0.4%+30) | ±(0.4%+30) |
| DC Current (A) | 400μA/4000μA/40mA/400mA/10A | ± (0.1%+15) | ± (0.1%+15) | ± (0.1%+15) |
| AC Current (A) | 400μA/4000μA/40mA/400mA/10A | ± (0.7%+15) | ± (0.7%+15) | ± (0.7%+15) |
| Resistance (Ω) | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ | ±(0.3%+8) | ±(0.3%+8) | ±(0.3%+8) |
| Capacitance (F) | 40nF/400nF/4μF/40μF/400μF/4mF/40mF | ±(1%+20) | ±(1%+20) | ±(1%+20) |
| Frequency (Hz) | 40Hz-400MHz | ±(0.01%+8) | ±(0.01%+8) | ±(0.01%+8) |
| Temperature (°C) | -40 °C - 1000°C | ±(1%+30) | ±(1%+30) | ±(1%+30) |
| Temperature (°F) | -40°F-1832°F | ±(1.5%+50) | ±(1.5%+50) | ±(1.5%+50) |
| Power (W) | 2500W | ±(2%+5) | ||
| Features | ||||
| Display Count | 39999 | 39999 | 39999 | |
| Auto Range | √ | √ | √ | |
| True RMS | √ | √ | √ | |
| Bandwidth (Hz) | 100KHz | √ | √ | √ |
| Duty Cycle | 10% - 90% | ±(1%+30) | ±(1%+30) | ±(1%+30) |
| Diode | √ | √ | √ | |
| Auto Power Off | √ | √ | √ | |
| Continuity Buzzer | √ | √ | √ | |
| Low Battery Indication | √ | √ | √ | |
| Data Hold | √ | √ | √ | |
| Relative Mode | √ | √ | √ | |
| MAX/MIN | √ | √ | √ | |
| Data Logging | 100 | 9999 | 100 | |
| USB Interface | √ | √ | √ | |
| Double Backlight | √ | √ | √ | |
| Analogue Bar Graph | √ | √ | √ | |
| Full Icon Display | √ | √ | √ | |
| Setup | √ | √ | √ | |
| Input Impedance for DCV | DC 400mV: Around 2.5GΩ,All Other Range: 10MΩ | √ | √ | √ |
| 4 - 20mA Loop | 0-100% | ±(1%+50) | ±(1%+50) | ±(1%+50) |
| Fused 10 A | √ | √ | √ | |
| Current Measurement Alarm | √ | √ | √ | |
| Voltage & Current AC+DC Measurement | √ | √ | √ | |
| General Characteristic | ||||
| Power | 9V Battery(6F22) | |||
| LCD Size | 73mm * 50 mm | |||
| Product Color | Red and Grey | |||
| Product Net Weight | 384g | |||
| Product Size | 200mm * 93mm * 40 mm | |||
| Standard Accessories | UT71C/UT71D-Battery, Test Lead, Alligator Clip, Test Clip, USB Interface Cable,PC Software CDe,Carrying Bag, Point Contact Temperature Probe | |||
| UT71E-Battery, Test Lead, Alligator Clip, Test Clip, USB Interface Cable,PC Software CD,Carrying Bag, Point Contact Temperature Probe,Power Adaptor | ||||
| Standard Individual Packing | Gift Box, English Manual | |||
| Standard Quantity Per Carton | 20 PCs | |||
| Standard Carton Measurement | 530mm *360mm * 385mm (0.073 CBM Per Standard Carton) | |||
| Standard Carton Gross Weight | 22 Kg | |||
Accessory
1.Battery, (not included)
2.Test Lead,
3.Alligator Clip,
4.Test Clip,
5.USB Interface Cable,
6.PC Software CD,
7.Carrying Bag
8.Point Contact Temperature Probe
