Home > Instruments & Meters > Meter for Electricity > Multimeter > UNI-T UT151C Modern Digital Multimeter LCD Handheld Mini Multipurpose Meter ac dc Volt Amp Ohm Capacitance Tester
UNI-T UT151C Modern Digital Multimeter LCD Handheld Mini Multipurpose Meter ac dc Volt Amp Ohm Capacitance Tester
US$ 1 - 20
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
ut151c
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
True RMS Digital Multimeters UNI-T UT139C AC DC Voltage and Current Auto Range Handheld MultimeterUS$ 18 - 38MOQ: 1 Piece -
True RMS Digital Multimeters UNI-T UT139B AC DC Voltage and Current Auto Range Handheld MultimeterUS$ 15 - 30MOQ: 1 Piece
-
True RMS Digital Multimeters UNI-T UT139A AC DC Voltage and Current Auto Range Handheld MultimeterUS$ 15 - 30MOQ: 1 Piece
-
Intelligent Digital Multimeter UNI-T UT71E Automotive Palm Size Multi-Purpose Meter LCD Voltmeter Ammeter Ohmmeter Auto RangeUS$ 100 - 160MOQ: 1 Piece
-
Digital Multimeters Palm Size UNI-T Ut33d Manual Range Diode & Data Hold Super Mini Pocket Multimeter Measure TemperatureUS$ 1 - 8MOQ: 5 Pieces
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
ut151c
Measuring Current Range
20mA- 20A
Measuring Voltage Range
200mV-1000V
Measuring Resistance Range
200Ω - 20MΩ
Measuring Capacitance Range
2nF/100μF
Measuring Inductance Range
none
Operating Temperature
-40 °C - 1000°C
Dimensions
186mm * 91mm * 39mm
UNI-T UT151C Modern Digital Multimeter LCD Handheld mini Multipurpose meter ac dc Volt Amp Ohm Capacitance Tester
Introduction
UT151C is stable performance, high reliability and handheld 3 1/2 digit digital multimeter, the whole circuit is designed to LSI, dual slope A / D converter as its core and with a fully functional overload protection, can be used to measuring DC and AC voltage, current, resistance, capacitance, diodes, batteries and circuit continuity. In addition, the series of instruments mA self resettable fuse gear, so that the user erroneous operation even when there is no need to replace the files in the mA fuse.
UT151C can be used to measure the family, school, smelting, telecommunications, manufacturing, oil, defense, electricity, chemical and other industries, it is the ideal tool for circuit / electrical equipment maintenance and repair.
Specification
| Specifications | Range | Best Accuracy | ||
| Model | UT151C | UT151D | UT151E | |
| DC Voltage (V) | 200mV/ 2V/ 20V/ 200V/ 1000V | ±(0.5%+1) | ±(0.5%+1) | ±(0.5%+1) |
| AC Voltage (V) | 2V/ 20V/ 200V/ 750V | ± (0.8%+3) | ± (0.8%+3) | ± (0.8%+3) |
| DC Current (A) | 2mA/ 20mA/ 200mA/ 20A | ± (0.8%+1) | ± (0.8%+1) | |
| 20mA/ 200mA/ 20A | ± (0.8%+1) | |||
| AC Current (A) | 20mA/ 200mA/ 20A | ± (1%+3) | ± (1%+3) | ± (1%+3) |
| Resistance (Ω) | 200Ω/ 2KΩ/ 20KΩ/ 200KΩ/ 2MΩ/ 20MΩ | ±(1%+2) | ||
| 200Ω/ 2KΩ/ 20KΩ/ 200KΩ/ 2MΩ/20MΩ/ 200MΩ | ±(1%+2) | |||
| 200Ω/ 2KΩ/ 20KΩ/ 200KΩ/ 20MΩ/ 200MΩ | ±(1%+2) | |||
| Capacitance (F) | 2nF/20nF/ 200nF/ 2μF/ 100μF | ±(4%+3) | ±(4%+3) | |
| 20nF/ 200nF/ 2μF/ 100μF | ±(4%+3) | |||
| Frequency (Hz) | 2KHz | ±(2.0%+5) | ||
| 20KHz | ±(1.5%+5) | ±(1.5%+5) | ||
| Temperature (°C) | -40 °C ~ 1000°C | ±(1%+3) | ±(1%+3) | |
| Temperature (°F) | -40°F~1832°F | ±(1%+4) | ||
| Features | ||||
| Display Count | 1999 | 1999 | 1999 | |
| Manual Range | √ | √ | √ | |
| Diode | √ | √ | √ | |
| Auto Power Off | √ | √ | √ | |
| Continuity Buzzer | √ | √ | √ | |
| Low Battery Indication | √ | √ | √ | |
| Data Hold | √ | √ | √ | |
| Input Impedance for DCV | ≥10MΩ | √ | √ | √ |
| General Characteristic | ||||
| Power | 9V Battery(6F22) | |||
| LCD Size | 63mm X 29 mm | |||
| Product Color | Red and Grey | |||
| Product Net Weight | 300g | |||
| Product Size | 186mm X 91mm X39 mm | |||
| Standard Accessories | UT151C/UT151E- Battery, Test Lead, Point Contact Temperature Probe | |||
| UT151D- Battery, Test Lead | ||||
| Standard Individual Packing | Gift Box, English Manual | |||
| Standard Quantity Per Carton | 40 PCs | |||
| Standard Carton Measurement | 645mm X 450mm X 340mm (0.099 CBM Per Standard Carton) | |||
| Standard Carton Gross Weight | 22.8 Kg | |||
Accessory
1. Battery,
2. Test Lead,
3. Point Contact Temperature Probe
