Intelligent Digital Double Clamp Phase Meter UNI-T UT265B Auto Range Multimeter AC Voltmeter Ammeter
Introduction
UT265B intelligent dual digital phase voltammetry table clamp latest selection of materials designed shell, with some vibration-proof, non-slip, high insulation jacket, using 240dots × 160dots LCD display, all the parameters with the screen display, clear, exquisite and luxurious appearance. For electric power, petrochemical, metallurgy, railway, industrial and mining enterprises, scientific research institutions, measurement sector. Especially for electricity billing system and protection systems, energy metering its power marketing department, electrical inspection, electrical inspection, biotechnology sector loading table electrical connection, protection, differential detection, start the test, transformer maintenance, or power training, digital phase voltammetry table, etc., and other skills contest.
Specification
| Specifications | Range | Best Accuracy |
| Model | UT265B | |
| AC Current (A) | AC 0.0mA~20.0A | ±(1.5%+3) |
| AC Voltage (V) | AC 0.00V~600V | ±(1.5%+3) |
| Frequency (Hz) | 45Hz~65Hz | ±(2%+3) |
| Active Power (W) | 0.0W~12kW | ±(3%+3) |
| Apparent Power (VAr) | 0.0VA~12kVA | ±(3%+3) |
| Reactive Power (VA) | 0.0VAR~12kVAR | ±(3%+3) |
| Power Factor | -1~+1 | ±0.03 |
| Phase Angle (°) | 0.0°~360° | ±1° |
| Features | ||
| Display Mode | LCD:240dots×160dots | √ |
| Clamp Size | Acuminate Current Clamp:7.5mm×13mm (Optional) Round Jaw Current Clamp:35mm×40mm (Optional) |
√ |
| Auto Range | √ | |
| RS-232 | √ | |
| Data Logging | 1500 | |
| LCD Backlight | √ | |
| Data Hold | √ | |
| Input Impedance for DCV | Around 2MΩ | √ |
| Auto Power Off | Around 15 Minutes | √ |
| Low Battery Indication | √ | |
| Sample Rate | About 2 times/second | √ |
| General Characteristic | ||
| Power | 1.5V Alkaline Batteries(LR6)X 6 | |
| Product Color | Red and Grey | |
| Product Net Weight | 550g | |
| Product Size | 196mm X 92mm X 54mm | |
| Standard Accessories | Batteries,Current Clamp: 2 pcs,Test Line: 4 pcs(2 yellow, 2 black) | |
| Standard Individual Packing | Gift Box, English Manual,Tool Box | |
| Standard Quantity Per Carton | 6 PCs | |
| Standard Carton Measurement | 530mm X 380mm X 395mm (0.075CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 17Kg | |
Accessory
1. Batteries, (not included)
2. Current Clamp: 2 pcs,
3. Test Line: 4 pcs(2 yellow, 2 black)
