Home > Products > Milling Machine > Universal Milling Machine X6140T/1 With Vertical-Horizontal Function
Universal Milling Machine X6140T/1 With Vertical-Horizontal Function
- qingdao.tianjin.shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
CNC Milling Machine XK6040 With Vertical-Horizontal Function
-
Universal Horizontal Milling Machine X6128A Knee-type Milling Machine
-
Universal Horizontal Milling Machine X5128A
-
Knee Type Universal Horizontal Milling Machine X6036A
-
Turret Mill-head Vertical CNC Milling Machine XK6350P for Sale
-
Vertical CNC Milling Machine XK7125
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | DATONG | Model Number | X6140T/1 | |
| Type | Universal | CNC or Not | CNC | |
| Voltage | 380V | Power(W) | 5.5kw | |
| Dimension(L*W*H) | 1800*2330*2100mm | Weight | 2900kg | |
| Certification | CE ISO9001 | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Universal Milling Machine X6140/1
Features:
1.The worktable X Y Z auto feed.
2.The surface of the working table and guide rail are hardening treatment.
3.The worktable could swivel ±45°,and coule install the dividing head ,easy to process the special workpieces.
4.Optional universal milling head.
Specification:
| Model | HM1688(X6140T) |
| Spindle bore | 7:24 ISO40(vertical) ISO50(horizontal) |
| Distance between spindle axis and table | 0-415mm |
| Spindle speed range | 40-1200rpm |
| Worktable size | 400*1700mm |
| Worktable travel(X/Y/Z) | 400*1110*450mm |
| Worktable feed speed(X/Y/Z) | 10step 20-630mm/min Rapid feed 1200mm/min |
| T-slot(number/width/space) | 5/18/62 |
| Main motor power | 5.5kw |
| Feed motor power | 1.1kw |
| Overall size | 1800*2330*2100mm |
| Weight | 2900kg |

The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
