ASAHI--AP-1600-TSG Corrugated Flat Bed Die-cutting Machine
- Guangzhou Shenzhen
- T/T
You May Like
Product Details
| Condition | New | Application | Other, Machinery & Hardware | |
| Packaging Type | Other, nude pack | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380V | Power | 34KW | |
| Place of Origin | Guangdong, China | Brand Name | NANTAI/ ASAHI | |
| Model Number | 1600TSG | Weight | 40tons | |
| Certification | CE | After-sales Service Provided | Overseas service center available |
Product Description
Features in performance
l Excusively for laminated paper and corrugated board with the latest servo-drive feeding system.
l Accurate registration from E flute to A fute.
l Complete stripped by stripping system and automatic grip edge waste removal device.
l High productivity is available for short run and long run job.
l High productivity, high precision and production speed is 5750 I.P.H.
l Made from super-thick and high quality steel,machine can be stronger and ucing vibration.
l Each part of machine with oil filler hole for daily maintenace, bringing higher precision and longer woriking life.
l Operation controlled by PLC.Status of paper can be monitored.
Press section
l Selected material and durable design.
l Precise and stable diecutting. Intermediated drive system to allow precisely controlled acceleration and deceleration of the gripper bar.
Stripping section
l With quick set (option), the male die can be set and fixed firmly from operation side.
l Lower stripping from can be locked with rachet handle from opration side. Upper and lower stripping from can be inserted into the mahcine from operation side to shorten setup time and for higher safety.
Cutting chase & Cutting plate
l Hard backed cutting chase to enable to enable short set up time.
l Soft plate can be mounted on the cutting plate for repeat order
Knock-off plate can be set and fixed from operation side once self-locking by cyliner
MODEL | 1600TSG | |
Maximum sheet size | 1100X1600mm | |
Minimum sheet size | 450X600mm | |
Miximum cutting size | 1080X600mm | |
Gripper size | 15(±5)mm | |
Inside size | 1120X1620mm | |
Maximum operational pressure | 350 tons | |
Applicable thickness of corugated board | 0.5-5mm | |
Maximum speed | 5750i.p.h | |
Required power supply | 34KW | |
Net weight of machine | 32tons |
Carton Sample
Factory View
