ASAHI-NANTAI Automatic Flat Bed Die Cutting Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
AP-165EII FLAT-BED DIECUTTING MACHINENegotiableMOQ: 1 Set -
ASAHI-Carton Flat-bed Die Cutting MachineNegotiableMOQ: 1 Set
-
ASAHI AP-1600-TSG Automatic Die Cutting MachineNegotiableMOQ: 1 Set
-
Laminated Paper Automatic Flat Bed Die-cutting MachineNegotiableMOQ: 1 Set
-
NANTAI-Carton Machine AP-1600 Automatic Flat-bed Die CuttingNegotiableMOQ: 1 Set
Condition
New
Application
Other, Machinery & Hardware
Packaging Type
Case
Automatic Grade
Automatic
Driven Type
Electric
Voltage
380V
Power
34kw
Place of Origin
Guangdong, China
Brand Name
Nantai/ Asahi
Model Number
AP-1600-TSG Automatic Platen Die-cutting Machine
Weight
36tons
Certification
CE
After-sales Service Provided
Overseas service center available
- Exclusively for colorful-mounted paper and corrugated board with upper haptor feeding system
- Accurate registration from E flute to double-wall A flute
- Complete stripping by a pair of male and female stripping forms and automatic grip edge waste removal.
- High productivity is available for short run and long run job.
- Safety devices protect operators and dual safety system stops machine run even power is cut off.
- All tooling set form outside of the machine.
Carton Sample
1.With newest developed top feeder, guarantees the smooth feeding of big size cardboard, and significantly
improves operation and production ablity.
2.Horizontal adjusting device adopts highly precise pull & push type, and the micro-adjusting can control on
the operation sade.
TECHNICAL DATA
| MODEL | AP-1600-TSG |
| Maximum sheet size | 1100x1600mm |
Minmum sheet size |
450x600mm |
| Maximum sheet cutting size | 1080x1600mm |
| Minimum gripper size | 10mm |
| Inside size | 1120x1648mm |
| Maximum operational pressure | 350tons |
| Maximum caliper of corrugated board | 5mm |
| Maximum speed | 5000i.p.h |
| Required power supply | 34kw(Main motor 22kw) |
| Net weight of machine | 32tons |
