Help CenterNANTAI-NT1428 Carton Flexo Printing Slotting Die-cutting Machine
Related Products
-
NANTAI-NT0920-IIAutomatic Flexo Printing Diecutting MachineNegotiableMOQ: 1 Set -
NANTAI-Carton Flexo Printing Slotting Machine NT1628NegotiableMOQ: 1 Set
-
Nantai-Bottom Vacuum Suction Flexo Printing Diecutting MachineNegotiableMOQ: 1 Set
-
NANTAI-Corrugated Flexo Printing Slotting MachineNegotiableMOQ: 1 Set
-
Carton Flexo Printing Slotting Diecutting MachineNegotiableMOQ: 1 Set
♦Two feeding systems are available for customers at custmer's choice,namely the fouar-shaft front roller feeding system and ejector back-kicking feeding system.
♦The built-in skip(intermittent)feeding feature makes offers the capability for making large-sized cartons.
♦The de-dusting device can substantially remove the dust and dirt from the printing surface of the sheets and enhance the printing quality.
♦All the transmission gears are made from quality steel through heat treatment and grinding.
♦The application of the spline-free shaft collar ensures long term operating performance and high alignment precision in printing.
♦Automatic zero-setting and automatic resetting.
♦Large-sized double-piece cartons can be produced by moving the middle die.
♦The powerful cylinder main lock for the whole machine makes the systerm more stable..
Carton Sample
TECHNICAL DATA
MODEL |
NT1428 |
Production Speed |
170sheet/min |
Max.Paper Sizes |
1320X2800mm |
Min.Paper Sizes |
380X700mm |
Interval feeding Max.Paper Sizes |
1750X2800mm |
Max.Printing Sizes |
1320X2800mm |
Standard Pringting Plate Thickness |
7.2mm |
Min.Slot Space |
170X170X170X170 240X70X240X70 |
Max.Depth |
300mm |
Factory View
WELCOME TO VISIT OUR COMPANY!
