NANTAI-Corrugated Flexo Printing Slotting Machine

Name: NANTAI-Corrugated Flexo Printing Slotting Machine
Brand: Nantai Precise Machinery
SKU: 110408157
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Plate Type:

Letterpress

Place of Origin:

Guangdong, China

Nantai Precise Machinery & Tech. Ltd. Foshan

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Letterpress

Place of Origin Guangdong, China

Brand Name Nantai Precise Machinery

Model Number NT1428 High-speed Flexo Printing Slotting Die-cutting Machine

Usage Other, corrugated

Automatic Grade Automatic

Voltage 380V/50HZ

Gross Power 35KW

Certification CE

After-sales Service Provided Overseas service center available

♦The built-in skip(intermittent)feeding feature makes offers the capability for making large-sized cartons.

♦The de-dusting device can substantially remove the dust and dirt from the printing surface of the sheets and enhance the printing quality.

♦All the transmission gears are made from quality steel through heat treatment and grinding.

♦The application of the spline-free shaft collar ensures long term operating performance and high alignment precision in printing.

♦Automatic zero-setting and automatic resetting.

♦Large-sized double-piece cartons can be produced by moving the middle die

FEEDING SECTION

The four-shaft front roller feeding system makes feeding more accurate. Feeding thin and bending sheets becomes easier.
The powerful cylinder main lock for the whole machine makes the system more stable.
The air flow and pressure are controlled by a frequency converter to satisfy the requirements for the thickness and size of the shets.

PRINTING SECTION

Applies hanging plate printing system, easy for plate changing, and has pedal switch, easy for plate hanging.
The circumferential adjustment mechanism of the printing platen applies plaetary gear structure.
Has auto low ink warning, avoiding damaging therubber roller and anilox roller.

SLOTTING SECTION

The gap between line-press wheel, feeding wheel and the slotting knife head is electrically adjustable, with adjusted data shown on the dial and the touch screen.
Has central knife moving, being able to produce large-sized 2-piece cartons.

DIE CUTTING SECTION

The rubber roller is designed as folded rubber cushion, providing convenience and ease for removal, installation adn replacement.
The transverse position of the die can be regulated through the eectric-digital adjuster. The total adjustable distance is about 20mm.
A PLC touch screen is used to control the spacing between the die roller and th rubber roller.

MODEL	NT1428
Production Speed	170sheet/min
Max.Paper Sizes	1320X2800mm
Min.Paper Sizes	380X700mm
Interval feeding Max.Paper Sizes	1750X2800mm
Max.Printing Sizes	1320X2800mm
Standard Pringting Plate Thickness	7.2mm
Min.Slot Space	170X170X170X170 mm 240X240X70mm
Max.Depth	300mm
