Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. Since our establishment in 2015, we have grown into a professional manufacturer with a factory spanning 10,000–30,000 square meters and a dedicated team of 201–300 employees. Our annual export value exceeds US$10 million, and we serve clients across North America, Europe, Asia, Africa, and Oceania. We proudly present our Skid-Mounted Integrated Evaporator — a compact, high-efficiency solution designed for concentration, separation, and wastewater reduction in various industries. This product comes with a 1-year warranty, free lifetime technical support, and a comprehensive Mill Test Report, ensuring you receive both performance and peace of mind.
Our evaporator is engineered to address common industrial challenges: limited floor space, high energy costs, and strict environmental regulations. The skid-mounted design integrates all major components onto a single frame, drastically simplifying installation and reducing on-site piping work. Whether you are treating chemical wastewater, concentrating food processing liquids, or recycling industrial solvents, this unit delivers consistent, reliable results with minimal operator intervention.
Key Features & Benefits
- Integrated Skid Design: Pre-assembled, pre-tested, and ready to connect — reduces installation time by up to 60% compared to traditional field-erected systems.
- High Thermal Efficiency: Utilizes multi-effect or MVR (Mechanical Vapor Recompression) technology, lowering energy consumption by 30–50% versus single-effect evaporators.
- Flexible Heat Source Options: Compatible with steam, electricity, thermal oil, or waste heat — adaptable to your existing utility infrastructure.
- Robust PLC Control: Fully automatic operation with touch-screen interface, real-time monitoring, and remote access capability. Minimal manual oversight required.
- Corrosion-Resistant Materials: Standard construction in SS304 or SS316L, with optional higher alloys for aggressive chemical environments.
- Comprehensive Documentation: Each unit ships with a detailed Mill Test Report (MTR) certifying material composition and mechanical properties, plus a complete quality dossier.
- Global Support: Our technical team provides free remote troubleshooting, commissioning guidance, and lifetime support. Spare parts are readily available.
Technical Specifications (Typical Configurations)
| Parameter | Range / Option |
|---|---|
| Evaporation Capacity | 100 – 10,000 L/h (customizable) |
| Operating Temperature | 40 – 120 °C (depending on application) |
| Vacuum Degree | -0.05 to -0.09 MPa (optional) |
| Power Supply | 380V / 50Hz (or as per local standard) |
| Heat Source | Steam / Electric / Thermal Oil / Waste Heat |
| Material of Construction | SS304 / SS316L (other alloys upon request) |
| Control System | PLC + HMI, Ethernet-ready |
| Dimensions (L×W×H) | Customized per capacity |
Why Choose Our Skid-Mounted Integrated Evaporator?
- Space-Saving: The compact skid reduces footprint by 40–50% compared to traditional layouts.
- Fast ROI: Lower energy consumption and automated operation cut operating costs significantly.
- Easy Maintenance: Modular design allows quick access to key components; routine cleaning is straightforward.
- Compliance Ready: Meets international standards for pressure vessels and electrical safety (certifications available upon request).
- Tested & Certified: Every unit undergoes factory acceptance testing (FAT) before shipment. Mill Test Report provides full traceability.
Our evaporator is ideal for industries such as chemical processing, pharmaceuticals, food & beverage, pulp & paper, textiles, and oil & gas. It handles solutions ranging from high-salinity brines to viscous organic liquids. With our free technical support, you receive ongoing assistance from our experienced engineers — from initial sizing to post-installation optimization.
Trust & Quality Assurance
As a manufacturer with a factory size of 10,000–30,000 m² and an annual export value exceeding US$10 million, we have supplied equipment to clients in North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, East Asia, and beyond. Our quality management system is certified under multiple standards including ISO9001, ISO14000, ISO16949, HACCP, TL900, OHSAS18001, and others. Every evaporator is backed by our dedicated after-sales team and a 1-year warranty covering manufacturing defects.
We understand that purchasing industrial equipment is a significant investment. That is why we provide a detailed Mill Test Report with each unit, documenting material grades and weld integrity. Combined with our free lifetime technical support, you can operate with confidence, knowing that expert assistance is just a call or email away.
Contact us today to discuss your specific evaporation requirements. Our technical team will provide a tailored solution, competitive pricing, and a fast quotation. Experience the reliability and efficiency of a Qingdao Conqinphi evaporator.
Frequently Asked Questions (FAQ)
Q1: What is the typical capacity range of this evaporator?
A: Our skid-mounted evaporators are available from 100 L/h up to 10,000 L/h. Larger capacities can be designed on request. We will match the unit to your feed flow and concentration needs.
Q2: Does the evaporator require special foundation or civil works?
A: No. The skid is fully self-contained and can be placed on a flat, level concrete floor. Only utility connections (power, feed, product, drain) are needed. Our installation guide is provided with the equipment.
Q3: What does the 1-year warranty cover?
A: The warranty covers manufacturing defects in materials and workmanship. Wear parts such as seals and gaskets are excluded but can be supplied at cost. We also offer extended warranty plans.
Q4: Is the Mill Test Report included in the delivery?
A: Yes, a complete Mill Test Report (MTR) is provided for all pressure-containing components, certifying material grades and mechanical properties. Additional documentation (e.g., NDT reports) can be included upon request.
Q5: Can the evaporator handle corrosive or hazardous liquids?
A: Yes. We can construct the unit in SS316L, duplex stainless steel, or other corrosion-resistant alloys. For hazardous environments, we offer explosion-proof electrical components and ATEX/IECEx certification options.
Q6: What kind of technical support is provided for free?
A: Free technical support includes remote troubleshooting via phone, email, or video call, as well as guidance during commissioning and operation. For on-site service, a fee may apply depending on location and scope.
Q7: What is the typical lead time?
A: Lead time depends on capacity and customization, typically ranging from 30 to 60 working days after order confirmation and design approval. We strive to meet urgent requests when possible.
Q8: Can I visit the factory before placing an order?
A: Absolutely. We welcome factory audits and inspections at our facility in Qingdao, Shandong, China. Please contact our sales team to schedule a visit. We can also arrange virtual factory tours via video call.
