Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. As a leading manufacturer established in 2015, we specialize in advanced wastewater treatment solutions. Our Automatic Skid-Mounted Integrated Evaporator with an IP65 control panel and 3-phase electric heating (50kW power) is designed to deliver reliable, efficient, and low-maintenance liquid concentration for a wide range of industries. This product combines robust engineering with smart automation to help you reduce disposal costs and meet environmental compliance – all in a compact, pre-assembled skid.
The evaporator is built for continuous operation, featuring a fully automated PLC control system housed in an IP65-rated enclosure, ensuring protection against dust and water jets. The three-phase electric heating element provides consistent thermal energy with precise temperature control, making it suitable for heat-sensitive or corrosive liquids. With 50kW power capacity, this unit can handle moderate throughput volumes (typically 500–1000 liters per day, depending on feed characteristics). Below are the key technical parameters:
| Parameter | Specification |
| Heating Power | 50 kW (3-phase) |
| Voltage | 380–480 VAC, 50/60 Hz |
| Control Panel | IP65 (NEMA 4X equivalent) |
| Material of Construction | 304 SS (316 SS optional) |
| Dimensions (L×W×H) | Customizable, typical 2.0×1.2×1.8 m |
| Weight | Approx. 800–1200 kg (depending on options) |
Key features and customer benefits:
- Skid-mounted integrated design – Pre-piped and pre-wired, ready for quick installation. No complex on-site assembly required.
- IP65 control panel – Fully sealed against dust and water, ideal for harsh industrial environments or outdoor placement.
- 3-phase electric heating – High energy efficiency, no combustion or exhaust gases, and easy to maintain compared to steam boilers.
- Automatic operation – PLC with HMI touchscreen controls end-to-end cycles: feed, concentration, discharge, and cleaning. Reduces operator intervention.
- Corrosion-resistant materials – Standard 304 stainless steel; optional 316L or higher alloys for aggressive wastewater streams (e.g., high chloride, acidic).
- Low maintenance – Self-cleaning cycle and easy-access design minimize downtime. Heating elements are modular for quick replacement.
- Customizable capacity – Multiple treatment volumes available; contact our engineers for tailored solutions.
Trusted by global industries: Qingdao Conqinphi Environmental Technology Group Co., Ltd. operates a factory spanning 10,000–30,000 square meters with 201–300 skilled employees. We have an annual export value exceeding US$10 million and serve markets across North America, South America, Europe, Asia, Africa, and Oceania. Our quality management systems adhere to internationally recognized standards (including ISO9001, ISO14000, and others available upon request). With over 8 years of manufacturing expertise, we deliver reliable, compliant solutions tailored to your wastewater reduction goals. Contact us today to discuss your project or request a quote – our team is ready to support you with technical drawings, performance data, and a competitive price.
Frequently Asked Questions (FAQ):
-
What is the typical evaporation capacity of a 50kW unit?
The capacity depends on feed concentration and liquid properties. In general, for water-based solutions, you can expect between 500 and 1000 liters per day of water evaporation. We can provide a detailed calculation based on your specific wastewater analysis. -
Can this evaporator handle corrosive or acidic liquids?
Yes, the standard model uses 304 SS, which is suitable for many non-chloride streams. For high chloride or acidic applications, we offer 316L or other alloys. Please share your liquid composition for a proper material recommendation. -
Does the unit require a special electrical installation?
It requires a 3-phase power supply (380–480 V, 50/60 Hz) with sufficient capacity (50kW plus auxiliary loads). A dedicated circuit breaker and grounding are recommended. Our technical team will provide wiring diagrams and installation guidelines. -
What certifications does this product have?
Our company holds multiple certifications including ISO9001, ISO14000, and others (HACCP, TL900, etc.) as per your region’s requirements. Specific product certifications (e.g., CE, UL) can be arranged upon request – please consult with our sales team for your target market. -
How often does the evaporator need maintenance?
The system includes an automated cleaning cycle. Manual inspection of seals, heating elements, and control components is recommended every 2–3 months under normal operation. Consumables (e.g., gaskets) are easy to replace. -
Can I integrate this evaporator with existing equipment?
Yes, the skid is designed with standard flanged connections (inlet/outlet) and a communication port for remote monitoring. Our engineers can customize interface dimensions and control signals to match your plant. -
What is the warranty period?
We offer a standard 12-month warranty from the commissioning date. Extended warranty options are available. All components are sourced from reputable suppliers, and we provide spare parts support for the machine’s lifetime. -
How long does it take to receive the equipment after ordering?
Lead time depends on customization and order quantity. Typically, a standard unit takes 30–45 days. For complex configurations, please allow 45–60 days. We will confirm the schedule with you before production.
