H07RN-F /H05RN-F 90°C Flexible Rubber Cable
·Excellent resistance to oil, acid, chemicals, water, ozone, extreme temperatures, cutting, tearing, and wear.
·Oil resistance (100℃, 24h)
·Resistance to artificial climate aging (1008h) irradiation
·Salt spray resistance (336h)
Suitable for turbines in wind power generation equipment and fixed installations inside towers or other similar occasions. Cables for wind power generation equipment manufacturers. Can be used in wind power generation equipment in onshore and offshore wind farms
It can also be used to connect heating units, industrial tools, mobile devices, and machinery such as vulcanizing plates, manually operated equipment, transport motors, etc. It can be applied in dry and wet areas under normal mechanical loads, outdoors and in explosion - hazardous areas. It is also suitable for industrial and agricultural applications as well as building installation and other application scenarios.
Conductor material: Bare copper stranded wire
Conductor class: Complies with DIN VDE 0295 Class 5, referring to IEC 60228 Class 5
Insulation: El4 type cross - linked elastomer mixture
Core wire identification: According to VDE 0293 - 308, up to 5 colored wires, from 6 black wires with white numbers, with or without GNYE
Stranding: Layered stranding
Outer sheath: EM2 type cross - linked elastomer mixture
Sheath color: Black
Rated voltage: H07RN -F :450/750 V H05RN -F 300/500V
Test voltage: 2.5KV
Minimum fixed bending radius: Complies with DIN VDE 0298 Part 3
Minimum moving bending radius: Complies with DIN VDE 0298 Part 3
Temperature class for fixed installation: -40°C/+90°C
Flame retardant standard: Complies with IEC 60332 - 1
Standard: VDE 0285 - 525 - 2 - 21/DIN EN 50525 - 2 - 21
Product identification: Aein beike SHANGHAI AEIN WIRE & CABLE CO.LTD Model Specification Voltage VDE
·Compliant with CE certification
·Compliant with SAA certification
·Compliant with CB certification
·Compliant with VDE certification
·Compliant with RoHS
·Compliant with VDE0285-525-2-1
Our advantages
Shanghai Aiyin Electric Wire & Cable Co., Ltd. Sichuan Branch owns a modern production base integrating production, quality inspection and development. The whole process of the company's production and operation is strictly in line with the requirements of ISO9001:2000 quality management system standard to implement comprehensive quality control, thus ensuring the product quality. The products produced by our company all meet international standards and can directly replace foreign products. It allows you to own products of international level at a reasonable price.
The main products produced by our company are: Drag chain cables, robot cables, servo cables, braider cables, highly flexible control cables, UL certified cables, EAC customs certified cables, CE certified cables, SAA Australian standard certified cables, TUV German standard certified cables, Japanese standard cables, traveling crane cables, reel cables, signal cables, crane cables, oil-resistant cables, cold-resistant cables, bucket wheel machine cables, overhead traveling crane cables, marine cables, zero buoyancy cables, Armored cables, RS-485, corrosion-resistant, acid and alkali-resistant cables, control cables, BUS bus, national standard CCC cables, PUR polyurethane cables, Self-supporting steel cable cables, elevator cables, cables for electrical installation,Special cables etc. After years of development, Shanghai Aiyin Electric Wire & Cable Co., Ltd. Sichuan Branch has been recognized by a large number of users with its good reputation and high-quality products.
