UL2570(SP) 80℃ 600V PVC Power Cable (Twisted Pair Shielded)
· Cold-resistant
· Soft
· Complies with RoHS standards
Data transmission cables, control and connection cables certified by UL & CUL, mainly used for transmitting analog and digital signals in process control facilities of measurement and control technology.
It enables lossless data and signal transmission and is suitable for high-demand drag chains and mobile drive systems. Internal wiring of electronic devices and electrical appliances.
The label may show the following content: "600 volts peak for electronic use only.
Conductor material: Bare copper or tinned copper
Conductor type: Complies with UL758 standards, ASTM B3 or ASTM B33 standards, DIN VDE 0295 Class 5 conductors or IEC 60228 Class 5 conductors
Core insulation: PVC (Automotive material)
Core identification:
≥20AWG: For 5 cores and below, color-coding is used for differentiation, including yellow/green ground wire, complying with n.DIN 47100. For multi-core cables with more than 5 cores, black cores are used,
and white ink numbering is used for differentiation (customized on demand if there are special requirements)
Cabling: Layered stranding, parallel structure
Sheath: PVC (-40°C sheath)
Outer sheath color: Gray RAL7001 or black RAL9005
Rated voltage: 300V
Test voltage: Core/core: 2.0kV
Conductor resistance: UL1581 ASTM Class C
Insulation resistance: +20°C, ≥20 MΩ x km;
Minimum bending radius, fixed: 7.5 x d
Minimum bending radius, moving: 15 x d
Temperature rating, fixed: -40°C/+105°C
Temperature rating, moving: -30°C/+105°C
Flame retardant rating: Self-extinguishing and flame retardant properties comply with UL1581VW-1; CSA C22.2 No.2556-15 FT1, FT2; IEC 60332-1-2 standards
Certifications: UL & CUL: UL1569, UL2570
CE: FLRYY. CE certification requirements need to be specified separately if needed.
Product identification: Aein beike E503807 AWM Model, Specification, Temperature, Voltage AWM I/I A/B Specification, Temperature, Voltage FT2 SHANGHAI AEIN Meter mark
· Complies with UL & CUL standards, UL758, CSA C22.2 No.210
· Complies with 2014/35/EU-Guideline (“Low Voltage Directive”) CE
· Customization is acceptable for products with special structures, other sizes, and colors of core wires and sheaths.
Our advantages
Shanghai Aiyin Electric Wire & Cable Co., Ltd. Sichuan Branch has a modern production base integrating production, quality inspection, and development. The entire process of the company's production and operation is strictly in line with the requirements of the ISO9001:2000 quality management system standard for comprehensive quality control, thus ensuring product quality. The products produced by our company all meet international standards and can directly replace foreign products. You can own products of international level at a reasonable price.
The main products we produce are: Drag chain cables, robot cables, servo cables, braider cables, highly flexible control cables, UL certified cables, EAC customs certified cables, CE certified cables, SAA Australian standard certified cables, TUV German standard certified cables, Japanese standard cables, crane cables, reel cables, signal cables, hoist cables, oil-resistant cables、Cold-resistant cables、Stacker-reclaimer cables、Crane cables、Marine cables、Zero-buoyancy cables、Armored cables、RS-485、Corrosion-resistant、Acid and alkali-resistant cables、Control cables、BUS、National standard CCC cables、PUR polyurethane cables、Self-supporting steel cable and elevator cables、Cables for electrical installation、Special cables etc. After years of development, Shanghai Aiyin Electric Wire & Cable Co., Ltd. Sichuan Branch has been recognized by a large number of users for its good reputation and high-quality products.
