Product Name:
FG16M16, TUV German Standard Certification
· Flame retardancy complies with IEC 60332-1-2
· Halogen-free complies with IEC 60754-1:2011 (Total amount of halogen acid gas)
· Corrosiveness of combustion gases complies with IEC 60754-2:2011 (Acidity)
· Low smoke density, complies with IEC 61034-2:2005+A12013+A2:2020
· Customization is acceptable for products with special structures, other sizes, and colors of core wires and sheaths.
Product Application:
Multi-core flexible power cables are suitable for installation locations in areas with fire risks and expected high population density. They are suitable for internal installation, as well as for wet places and external installation; used for installation on surface-mounted or metal structures; direct burial underground is allowed.
Installed on surface-mounted or metal structures; direct burial underground is allowed.
Product Structure:
Conductor Material: Bare Copper Wire
Conductor Type: Complies with IEC 60228 cl. 5 standard, cl.2 is optional
Insulation: G16 type Hard Ethylene Propylene Rubber (HEPR) Compound
Sheath: M16 type Halogen-free Thermoplastic Compound
Core Identification: Two cores: Red, Blue; Three cores: Red, Yellow, Green; Four cores: Red, Yellow, Green, Blue; Five cores: Red, Yellow, Green, Blue, Yellow/Green
Stranding: Layered Stranding
Rated Voltage: 0.6/1kV
Test Voltage: 3.5 kV
Conductor Rated Temperature: 90°C
Minimum bending radius for fixed installation: 7.5 x d
Minimum bending radius for flexible installation: 15 x d
Temperature range for fixed installation: -15°C/+90°C
Temperature range for flexible installation: -5°C/+90°C
Flame retardant rating: IEC 60332-1-2, EN50265-2-1
Standards: IEC60502-1, DIN VDE 0295
Product identification: Aein beike SHANGHAI AEIN WIRE& CABLE CO.LTD Model, Specification, Voltage, CE, Meter marking
Certification standards:
·Compliant with RoHS
·Compliant with 2014/35/EU - Guideline (“Low Voltage Directive”) CE
·Complies with TUV certification
