UL21320 (P) 80°C 1000V PUR Power Cable (Shielded)
· Compliant with RoHS
· UV-resistant
· Flame retardant compliant with CSA C22.2 No.2556-15 FT2
· Oil-resistant, compliant with UL1581:IRM 902, DIN EN 60811-1-2
· Strong resistance to greases, coolants and lubricants
The cable can be used as power, control and connection cables in power facilities for lossless data and signal transmission, fixed installation and mobile applications, without tensile stress and no specified cable routing. It is more durable in harsh environments with mechanical stress; it can resist various lubricants containing mineral oil components, diluted acids, alkaline aqueous solutions and other chemical media; it has a wide temperature range and is suitable for severe climate environments. It can be used for internal wiring and external interconnection of electronic devices, with oil resistance, wear resistance, acid and alkali resistance, water resistance and UV resistance characteristics.
The cable can be used as power, control and connection cables in power facilities for lossless data and signal transmission, fixed installation and mobile applications, without tensile stress and no specified cable routing. It is more durable in harsh environments with mechanical stress; it can resist various lubricants containing mineral oil components, diluted acids, alkaline aqueous solutions and other chemical media; it has a wide temperature range and is suitable for severe climate environments. It can be used for internal wiring and external interconnection of electronic devices, with oil resistance, wear resistance, acid and alkali resistance, water resistance and UV resistance characteristics.
Conductor material: Bare copper
Conductor class: Compliant with UL758 standard, ASTM B3 or ASTM B33 standard, VDE 0295 Class 5 Conductor pt.4 or IEC60228 Class 5 Conductor pt.4
Core insulation: PVC, XLPE, TPE are optional
Core identification: Compliant with DIN VDE 0293, black with white numbering, 1xGNYE
Cabling: Core wires are stranded in layers or in parallel structure
Shielding: Tinned copper wire braiding, shielding density > 70%
Outer sheath: Flame-retardant PUR
Outer sheath color: Gray RAL7001 or black RAL9005
Rated voltage: 1000 V
Test voltage: 3 kV
Conductor resistance: UL1581 ASTM Class C
Insulation resistance: PVC: +20°C ≥20 MΩ x km; PVC: +20°C ≥200 MΩ x km
Minimum bending radius (fixed): 4 x d
Minimum bending radius (mobile): 7.5 x d
Working temperature (fixed, min/max): -40°C/+80°C
Temperature rating (mobile, min/max): -30°C/+80°C
Flame-retardant rating: Self-extinguishing and flame-retardant, compliant with FT2
Oil resistance: UL1581: IRM 902; Compliant with DIN EN 60811-2-1
Certifications: UL & CUL: UL1032, UL10914, UL11122, UL3237, UL3820, UL21320
CE: DYYU11Y. If CE certification or halogen-free requirement is needed, please indicate separately.
Product identification: Aein bei ke E503807 AWM Model Specification Temperature Voltage AWM I/Ⅱ A/B Specification Temperature Voltage FT2 SHANGHAI AEIN
· Compliant with UL & CUL standards, UL758, CSA C22.2 No.210
· Compliant with 2014/35/EU-Guideline (“Low Voltage Directive”) CE
· Customization is available for products with special structures, other sizes, and colors of core wires and sheaths.
Our advantages
Shanghai Aiyin Electric Wire & Cable Co., Ltd. Sichuan Branch owns a modern production base integrating production, quality inspection and development. The whole process of the company's production and operation is strictly in line with the requirements of the ISO9001:2000 Quality Management System Standard to implement comprehensive quality control, thus ensuring the product quality. All products produced by our company meet international standards and can directly replace foreign products. It allows you to own internationally - level products at a reasonable price.
The main products produced by our company include: Drag chain cables, robot cables, servo cables, braider cables, highly flexible control cables, UL - certified cables, EAC customs - certified cables, CE - certified cables, SAA Australian standard - certified cables, TUV German standard - certified cables, Japanese standard cables, crane cables, reel cables, signal cables, hoist cables, oil - resistant cables, cold - resistant cables, bucket wheel machine cables, overhead traveling crane cables, marine cables, zero - buoyancy cables, Armored cables, RS - 485, corrosion - resistant, acid - and alkali - resistant cables, control cables, BUS cables, GB CCC cables, PUR polyurethane cables, Self - supporting steel cable cables, elevator cables, cables for electrical installation, Special cables, etc. After years of development, our company has been recognized by a large number of users with good reputation and high - quality products.
