UL3271 105℃ 1000V XLPE Single-core Cable
· It has strong resistance to acids, alkalis and specific types of oils.
· Halogen-free and flame-retardant
· It shall not be directly laid in trays, channels or pallets (except for potential compensation).
· All common standard colors are available.
Halogen-free cross-linked stranded wires certified by UL & CUL, used for wiring in telecommunication units, electrical modules and telecommunication facilities. This cable is a halogen-free, environmentally friendly single-core cable.
It is used for internal wiring of equipment. Signal facilities are allowed to be laid in pipes on the wall and in the wall.
Conductor material: Bare copper
Conductor type: Complies with UL758 standard and Class 5 of IEC 60228
Core insulation: XLPE
Core identification: Different colors
Rated voltage: 600V
Test voltage: ≤2AWG 2000V; 1 - 4/0 2500V; 250kcmil - 500kcmil 3000V; 501kcmil - 1000kcmil 3500V
Conductor resistance: UL1581 ASTM Class C
Minimum bending radius (fixed): 4 x d
Minimum bending radius (movable): 15 x d
Operating temperature (fixed, minimum/maximum): -40°C/125°C
Halogen-free property: Complies with IEC 60754
Smoke density: Complies with IEC 61034
Flame-retardant grade: Self-extinguishing and flame-retardant, complies with IEC60332-1-2, FT2
Standards: UL758, CE
Product identification: E503807 AWM Model Specification Temperature Voltage or C AWMIA Specification Temperature Voltage FT2 SHANGHAI AEIN
·Complies with RoHS standards
·Complies with Directive 2014/35/EU ("Low Voltage Directive") CE
