Aein bei ke ® Crane Flat 8180 Flexible Flat Cable
·UV, ozone and weather resistance comply with EN 50396 and HD 605 S2
·Resistant to coolant, microorganisms, weak acids and alkalis
Widely used in crane reel equipment. The cable is soft, wear-resistant, weather-resistant, tear-resistant and has excellent performance. The cable can be designed to incorporate galvanized anti-tensile steel wire ropes as the anti-tensile
reinforcing elements to enhance the anti-tensile performance of the cable, meeting the requirements of lifting equipment in occasions and environments with high anti-tensile requirements.
Conductor material: Bare copper stranded wire
Conductor class: Comply with DIN VDE 0295 Class 5, refer to IEC 60228 Class 5, GB/T3956 Class 5
Core insulation: DQPVC-J-70-001 (NJ-83)
Core identification: Comply with VDE0293-308, more than 5 colored wires, from 6 black wires with white numbers and GNYE
Stranding: Two-core twisted pair; paired stranding; layered stranding, untwisting process
Outer sheath: DQPVC-H-70-002 (B-70A)
Sheath color: Black RAL5005; Gray RAL7004; Orange RAL2004
Rated voltage: 300/500V; 0.6/1kV
Test voltage: 2.5 kV; 3.5kV
Ampacity: Comply with DIN VDE 0298
Minimum fixed bending radius: 10 X D
Minimum moving bending radius: 7.5 X D
Temperature class, fixed minimum/maximum: -30°C/+70°C
Temperature class, moving minimum/maximum: -20°C/+70°C
Conductor temperature: +70°C
Tensile load: 15N/mm2
Certification: CE
.Complies with RoHS
·Complies with 2014/35/EU-Guideline ("Low Voltage Directive") CE
·Other dimensions, core colors, and sheath colors can be customized.
Our advantages
Shanghai Aiyin Electric Wire & Cable Co., Ltd. Sichuan Branch has a modern production base integrating production, quality inspection, and development. The whole process of the company's production and operation is strictly in line with the requirements of the ISO9001:2000 Quality Management System standard to implement comprehensive quality control, thus ensuring the product quality. The products produced by our company all meet international standards and can directly replace foreign products. It enables you to own products of international level at a reasonable price.
The main products of our company are: Drag chain cables, robot cables, servo cables, braider cables, highly flexible control cables, UL-certified cables, EAC customs-certified cables, CE-certified cables, SAA Australian standard-certified cables, TUV German standard-certified cables, Japanese standard cables, traveling crane cables, reel cables, signal cables, crane cables, oil-resistant cables, cold-resistant cables, bucket wheel machine cables, overhead traveling crane cables, marine cables, zero-buoyancy cables,Armored cables, RS-485, corrosion-resistant, acid and alkali-resistant cables, control cables,BUS cables, national standard CCC cables, PUR polyurethane cables,Self-supporting steel cable cables, elevator cables, cables for electrical installation,Special cables, etc. After years of development, our company has been recognized by a large number of users with good reputation and high-quality products.
