N2XY(SWA) EU CE Certified XLPE Insulated Steel Wire Bundle Armored Power Cable
· Black type sheath: Can be used for anti-ultraviolet
· Flame retardancy
These cables are used for power supply in low-voltage installation systems. "They are suitable for installation indoors and outdoors, in cable ducts, underground, in power plants and switchyards, local energy distribution,
in industrial plants and other places where there is no risk of mechanical damage.
Conductor material: Bare copper wire
Conductor class: Complies with IEC 60228 cl.5 standard
Insulation: Cross-linked polyethylene (XLPE) or polyvinyl chloride (PVC)
Core identification: Black cores with white numbers, with or without GNYE
Stranding: Layered stranding
Outer sheath: PVC
Sheath color: Black, RAL9005 or gray RAL7001
Rated voltage: 0.6/1kV
Test voltage: 4kV
Conductor resistance: Complies with IEC 60228 cl.5 standard
Capacitance: Core/core approx. 120 nF/km; core/shield approx. 160 nF/km
Minimum bending radius (fixed): 7.5 x d
Minimum bending radius (mobile): 15 x d
Temperature class (fixed): -15°C/+90°C
Temperature class (mobile): -5°C/+90°C
Flame retardant class: IEC 60332-1-2
Standards: HD 603-3G IEC60502
Product identification: Aein beike SHANGHAI AEIN WIRE& CABLE CO.LTD Model Specification Voltage CE Meter mark
Complies with RoHS standards
·Complies with the 2014/35/EU Directive ("Low Voltage Directive") CE
