Help CenterFg16oh1r16 Tuv German Standard Certification, 0.6/1kv, 90 °c Epr Insulation, Pvc Sheath
Related Products
-
en 50288-7-re-2x(st)h Swah Lszh Pimf Tuv Certified Instrumentation CableUS$ 0.61 - 0.7MOQ: 1000 Meters -
s 600v -40°c/+105°c ep Insulated, ep Sheathed Rubber Cable With Canadian CertificationUS$ 0.89 - 0.98MOQ: 1000 Meters
-
Sjtw/sjt 105°c 300v Ul62 Standard Automotive Wire, Flame Retardant, Highly Flexible, WaterproofUS$ 0.87 - 1.04MOQ: 1000 Meters
-
Cmr Canada Csa Certified Communication Fire-resistant Cable, Fep Insulation, Pvc Sheath, 300vUS$ 1.33 - 1.52MOQ: 1000 Meters
-
Svt 105°c 300v Flame-retardant, Highly Flexible, Cold-resistant Automotive Wire for Indoor Use, Complying With Ul62 StandardUS$ 0.9 - 1.04MOQ: 1000 Meters
Product Introduction
01 Product Application
It is suitable for indoor and outdoor installation, and also suitable for wet places and external installation. It is used for installation on surface-mounted or metal structures and allows direct burial underground. When a certain degree of protection against electromagnetic interference is required, it is usually used for the interconnection of machines or machine parts.
02Product Features
The flame retardancy complies with IEC 60332-1-2.
Customization is acceptable for products with special structures, other sizes, and colors of cores and sheaths.03 Technical Certification
Complies with RoHS.
Complies with 2014/35/EU-Guideline ("Low Voltage Directive") CE.
Complies with TUV certification.
Product Structure
Conductor material: Bare copper wire
Conductor type: Complies with IEC 60228 cl. 5 standard, cl. 2 is optional
Shielding: Copper-plastic composite tape
Insulation: G16 type hard ethylene propylene rubber (HEPR) compound
Sheath: R16 type PVC
Core identification: Two cores: red and blue; Three cores: red, yellow and green; Four cores: red, yellow, green and blue; Five cores: red, yellow, green, blue and yellow/green
Sheath color: Gray RAL7001
Stranding: Layered stranding
Rated voltage: 0.6/1kV
Test voltage: 3.5 kV
Conductor resistance: Complies with IEC 60228 cl. 5 standard
Conductor rated temperature: 90°C
During short circuit (the long duration does not exceed 5s), the cable conductor temperature does not exceed 250 °C
Minimum bending radius for fixed installation: 7.5x d
Minimum bending radius for mobile installation: 15x d
Fixed temperature: -15°C / +90 °C
Mobile temperature: -5 °C / +90 °C
Flame retardant rating: IEC 60332-1-2, EN50265-2-1
Standards: IEC60502-1, DIN VDE 0295
Product identification: Aein bei ke SHANGHAI AEIN WIRE ＆ CABLE CO.,LTD Model, Specification, Voltage CE Meter mark
