Product Introduction
01 Product Application
Firefighting cables are mainly used for emergency lighting, fire observation, signal sensing systems, blower systems, communication call systems, control equipment systems, fire pumps, and fire alarm system circuit cables. For example: school offices, airports, tunnels, railway stations, computers, alarm systems, traffic control systems, fire prevention systems, etc.
02 Product Features
Flame retardant Class P
Self - extinguishing
Fireproof
03 Technical Certification
Standard: UL1424/NEC Article 760
Compliance: FPLP/CMR/CL3R, Flame test UL1666
RoHS (European Directive 22/95/EC)
Structural Specifications
Conductor material: Bare copper
Conductor grade: Complies with IEC60228 cl.1 standard, Complies with IEC60228 cl.2 standard
Core insulation: LS - PVC
Drain wire: 1/0.404±0.008mm solid tinned copper (optional)
Shielding: Aluminum foil (optional)
Outer sheath: LS - PVC
Sheath color: Red
Test voltage: DC: 2500V/2S, no breakdown
Maximum resistance: 5.310 hms/KM at 20°C
Minimum insulation resistance: 100 MQ/KFT at 15.6°C
Operating voltage: 300V
Temperature rating: -20°C/+105°C
Standard: UL1424
Flame propagation (single insulation): UL2556
Flame propagation (multiple cables): UL1666
