Product Introduction
01 Product Applications
This cable is mainly used for indoor light portable devices, such as vacuum cleaners, blenders, household appliances, light electric tools, etc.
02 Product Features
UL Certification
Flame retardancy meets VW-1
High flexibility and cold resistance
03 Technical Certifications
Complies with RoHS standards
UL Certification
Complies with UL62/CSA-C22.2, UL1581
Product Structure
Conductor material: Flexible stranded copper conductor
Conductor grade: Complies with UL62 standards
Core insulation: Special PVC
Core identification: Black core with white numbers, with or without GNYE
Stranding: Insulated cores are stranded into a cable with the optimal pitch
Outer sheath: Special PVC
Outer sheath color: Black RAL9005 or grey RAL7001 (optional)
Rated voltage: 300V
Test voltage: 2.5kV
Bending radius: 7.5xd
Temperature rating: -40°C/+105°C
Flame retardant rating: Self-extinguishing, meets UL VW-1 standards
Standard: UL62
Product identification Aein bei ke E503806 (UL) Model *x* AWG (*mm2) Temperature Voltage c(UL) Model *x* mm2 (*AWG) Temperature Voltage WW-1
